Singer M1500 User Manual

6
Winding the Bobbin
- Place the thread and spool pin felt (a) onto the spool pin. (1)
- Draw the thread from the spool through the upper thread
guide. (2)
- Wind the thread clockwise around bobbin winder tension
discs. (3)
- Thread bobbin as illustrated and place on spindle. (4)
- Push bobbin spindle to right. (5)
- Hold thread end. (6)
- Step on foot control pedal. (7)
- Release the pedal after a few turns. Release the thread
and cut as close as possible to the spool. Press the pedal
again. Once the spool is full, it rotates slowly. Release the
pedal and cut thread. (8)
- Push bobbin spindle to left (9) and remove.
Please Note:
When the bobbin winder spindle is in “bobbin winding”
position, the machine will not sew and the hand wheel will
not turn. To start sewing, push the bobbin winder spindle
to the left (sewing position).
a
Threading the Machine

Singer M1500 Specifications

General

Buttonhole Type	4-step
Presser Foot	Snap-On
Free Arm	Yes
Reverse Lever	Yes
Type	Mechanical
Stitch Width	5mm
Buttonhole Styles	1
Needle Positions	3
Built-in Needle Threader	No
Drop Feed	No
Stitch Applications	Basic
Stitch Options	Straight, Zigzag, Blind Hem
Presser Feet Included	All-Purpose Foot, Buttonhole Foot, Zipper Foot, Button Sewing Foot
