9
This is a simple operation but it is important to carry out
correctly as by not doing so several sewing problems could
result.
- Raise the needle to its highest position by turning the
handwheel towards you (counterclockwise) so that the
mark on the handwheel points directly up. Raise the
presser foot to release the tension discs. (1)
Note: For safety, it is strongly suggested you turn off the
power before threading.
- Lift up the spool pin. Place the spool of thread on the
holder with the thread coming off the spool as shown. For
small thread spools, place small side of spool holder next
to spool.(2)
- Draw thread from spool through the upper thread guide (3)
and pulling thread through pre-tension spring as illustrated.
(4)
- Thread tension module by leading thread down right
channel and up left channel. (5) During this process it is
helpful to hold the thread between the spool and thread
guide.
- At the top of this movement pass thread from right to
left through the slotted eye of the take-up lever and then
downwards again. (6)
- Now pass thread behind the thin wire needle clamp guide
(7) and then down to the needle which should be threaded
from front to back.
- Pull about 6-8 inches of thread to the rear beyond the
needle eye. Trim thread to length with built in thread cutter.
(8)
Threading the Upper Thread
