I NSTALLATION
2-6
Phone Line Configuration
Installing a Full-Rate Connection
If you are using a full-rate (G.dmt) connection, your service provider will
attach the outside ADSL line to a data/voice splitter. Use a straight
through CAT-5 Ethernet cable (RJ-45) to connect the Barricade to the
cable/DSL modem.
Figure 2-3. Installing with a Splitter
Voice
Data
Residential
Connection
Point (NID)
Plain Old
Telephone
System (POTS)
or
Ethernet
hub or switch
Barricade
Splitter
Modem
