Sonoff DW2-Wi-Fi User Manual

SONOFF TECHNOLOGIES CO., LTD.
English
Product Introduction
The device weight is less than 1 kg.
The installation height of less than 2 m is recommended.
LED indicator
Align the mark lines
Transmitter
Magnet
Pairing button
Bluetooth Pairing Mode
Unable to discover the router
Connect to the router but fail to connect to Wi-Fi
Flashes
Flashes quickly once
Flashes quickly twice
Historical operation
records
Alarm push
notification
Battery level
Share Control
DW2-Wi-Fi is a Wi-Fi wireless door/window transmitter which triggers the transmitter
by separating the magnet for more than 20mm from the transmitter, then the
transmitter will send an alarm message and pushes it to APP. You can share the
device with your family to check the door/window status together.
LED indicator status instruction
Features

Sonoff DW2-Wi-Fi Specifications

General

Interface	Wi-Fi
Certification	FCC
Product color	White
Housing material	Polycarbonate (PC)
Installation type	Adhesive tape
Operating frequency	2400 MHz
Security algorithms	128-bit AES, AES, TKIP, WEP, WPA, WPA2
Connectivity technology	Wireless
Suitable for indoor use	Yes
Ambient temperature (max)	40 °C
Ambient temperature (min)	-10 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Mobile operating systems supported	Android, iOS
Battery type	AAA
Battery voltage	1.5 V
Power supply input voltage	3 V
Number of batteries supported	2
Sustainability certificates	CE, RoHS

Weight and Dimensions

Depth	19 mm
Width	31 mm
Weight	28 g
