Sonoff DW2-Wi-Fi User Manual

Door
Window
Note:
● Do not install outside the door/window.
● Do not install in the unstable position or in the place exposed to
rain or moisture.
● Do not install near wiring or magnetic object.
Application
Replace batteries
SONOFF TECHNOLOGIES CO., LTD.
English

Sonoff DW2-Wi-Fi Specifications

General

Interface	Wi-Fi
Certification	FCC
Product color	White
Housing material	Polycarbonate (PC)
Installation type	Adhesive tape
Operating frequency	2400 MHz
Security algorithms	128-bit AES, AES, TKIP, WEP, WPA, WPA2
Connectivity technology	Wireless
Suitable for indoor use	Yes
Ambient temperature (max)	40 °C
Ambient temperature (min)	-10 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Mobile operating systems supported	Android, iOS
Battery type	AAA
Battery voltage	1.5 V
Power supply input voltage	3 V
Number of batteries supported	2
Sustainability certificates	CE, RoHS

Weight and Dimensions

Depth	19 mm
Width	31 mm
Weight	28 g
