Sony Bravia XBR-65X750D User Manual

15
US
US
The , +, and – buttons cannot be located
on the TV.
 See below illustration for location of the
buttons on the TV.
The illumination LED is turned on.
 If you do not wish to light up the illumination
LED, you can turn it off.
Press HOME, then select [Settings] 
[Illumination LED]  [Off].
Cannot connect to a wireless router by
WPS (Wi-Fi Protected Setup).
 If you use WEP security, select [Easy] 
[Wi-Fi]  [Connect by scan list]. Then, select
the network name (SSID) you want to
connect.
Cannot find the required network name
in network setup.
 Select [[Manual entry]] and press to enter
network name.
Specifications
System
Television system
NTSC: American TV standard
ATSC (8VSB terrestrial): ATSC compliant 8VSB
QAM on cable: ANSI/SCTE 07 2000 (Does not
include CableCARD functionality)
Channel coverage
Analog terrestrial: 2 - 69 / Digital terrestrial:
2 - 69
Analog Cable: 1 - 135 / Digital Cable: 1 - 135
Panel system
LCD (Liquid Crystal Display) Panel, LED
Backlight
Speaker output
10 W + 10 W
Wireless technology
Protocol IEEE802.11ac/a/b/g/n
Bluetooth Version 4.1
Input/Output jacks
CABLE/ANTENNA
75-ohm external terminal for RF inputs
VIDEO IN 1
Video / Audio input (mini jack)
COMPONENT IN
YPBPR (Component Video): 1080p (60 Hz),
1080i (60 Hz), 720p (60 Hz), 480p, 480i
Audio input (phono pin jack)
VIDEO IN 2
Video input (common phono pin with Y
input)
HDMI IN 1/2/3/4 (Support 4K resolution,
HDCP 2.2-compatible)
Video:
4096 × 2160p (60 Hz)*
1,
*
2
, 4096 × 2160p (24
Hz)*
1
, 3840 × 2160p (60 Hz)*
2
,
3840 × 2160p (24, 30 Hz), 1080p (30, 60 Hz),
1080/24p, 1080i (60 Hz), 720p (30, 60 Hz),
720/24p, 480p, 480i, PC Formats
*
1
3840 × 2160p is displayed when
4096 × 2160p is input
*
2
HDMI IN 2 / 3 only.
Audio: 5.1 channel linear PCM: 32, 44.1, 48,
88.2, 96, 176.4 and 192 kHz, 16, 20 and 24
bits, Dolby Digital, Dolby Digital Plus and DTS
ARC (Audio Return Channel) (HDMI IN 3 only)
(Two channel linear PCM, Dolby Digital,
Dolby Digital Plus, DTS)
Rear of TV

Sony Bravia XBR-65X750D Specifications

General

Screen Type	led
Wall Mount	300mm x 300mm
Features	live colour; bravia sync function
Tuner	digital
Screen Size	64.5 inches, 65 inches
Refresh Rate	120hz
Closed Captioning	yes
Motion Enhancement	motionflow xr 960
HDR	yes
HDR Format	hdr 10, hybrid log-gamma (hlg)
Built-In Speakers	yes
Surround Sound	other
Speakers Output	20 watts
HDMI ARC Ports	yes
USB Ports	3
USB 2.0 Ports	2
USB 3.0 Ports	1
Ethernet	yes
RF Antenna	yes
Bluetooth	true, 4.1
Network	built-in wi-fi, ethernet
Headphones Output	yes
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	2
DVI	0
VGA Ports	0
SmartTV	android tv
Smart Applications	amazon alexa, google assistant
Remote Control	standard
3D	no
Power Consumption	184 kilowatt hours
Depth with Stand	11.6 inches
Height with Stand	35.5 inches
Width with Stand	57.6 inches
Net Weight with Stand	50 pounds
Depth without Stand	3.1 inches
Height without Stand	33.6 inches
Net Weight without Stand	47.4 pounds
