Sony Bravia XR-77A80J User Manual

D:\SONY TV\SY21_AT_UCM_RG_111\AT UCM US\5026348111_US.fm master page: Left
XR-77A80J / 77A80CJ / 65A80J / 65A80CJ / 55A80J
5-026-348-11(1)
4
US
Securing the TV
Preventing the TV from Toppling
• Secure the TV to a wall and/or Stand.
• Do not allow children to play or climb on furniture and TV
sets.
• Avoid placing or hanging items on the TV.
• Never install the TV on:
 slippery, unstable and/or uneven surfaces.
 furniture that can easily be used as steps, such as a
chest of drawers.
• Install the TV where it cannot be pulled, pushed, or
knocked over.
• Install the TV so that the TV’s Table-Top Stand does not
protrude out from the Stand (not supplied). If the
Table-Top Stand protrudes out from the Stand, it may
cause TV set to topple over, fall down, and cause personal
injury or damage to the TV.
• Route all AC power cords and connecting cables so that
they are not accessible to curious children.
Recommended Measures to Secure the
TV
Consider the following measures when securing your TV to
a Stand (not supplied).
1 Secure the Stand for the TV.
Make sure the Stand can adequately support the weight
of the TV. Use two angle braces (not supplied) to secure
the Stand. For each angle brace use the appropriate
hardware to:
• Attach one side of the angle brace to the wall stud.
• Attach the other side to the Stand.
2 Secure the TV to the Stand.
Use the optional hardware listed as follows (not
supplied):
• M6 machine screws (screwed into the TV’s rear cover).
• A screw or similar (attach it to the Stand).
• Rope or chain (strong enough to support the weight of
the TV). Make sure that there is no excess slack in the
rope or chain.
The length of the M6 machine screw differs depending
on the rope or chain diameter. Please refer to below
illustration.
3 Anchor the TV to the wall by using bolts, wall anchor and
chain (or rope).
Sony strongly recommends taking
measures to prevent the TV from
toppling over.
Unsecured TVs may topple and result in
property damage, serious bodily injury
or even death.
Angle brace
(not supplied)
Stand
2
4
3
1
M6 machine screw
(not supplied)
Rope or chain (not supplied)
Screw (not supplied)
1.5 N·m
{15 kgf·cm}
Screw hole on the rear cover
10 mm – 14 mm
Screw (M6)
TV’s rear cover
Rope or chain
Wall-mount holes
Rope or
chain (not
supplied)
M6 eye bolts (not supplied)

Sony Bravia XR-77A80J Specifications

General

Screen Type	oled
Color	black
Wall Mount	300mm x 300mm
Tuner	digital
Screen Size	76.7 inches, 77 inches
Resolution	4k (2160p)
Refresh Rate	120hz
Closed Captioning	yes
Motion Enhancement	motionflow xr 240
HDR	yes
HDR Format	hdr 10, hybrid log-gamma (hlg), dolby vision
Built-In Speakers	true, downward firing
Surround Sound	dts digital surround
HDMI Ports	4
HDMI 2.1 Ports	2
HDMI ARC Ports	yes
USB Ports	2
USB 2.0 Ports	2
Ethernet	yes
RF Antenna	yes
Bluetooth	true, 4.2
Network	built-in wi-fi, ethernet
Digital Optical Audio Outputs	1
Component Video Inputs	0
Composite Video Inputs	1
DVI	0
SmartTV	google tv
Streaming Services	paramount+, disney+, hbo max, hulu, netflix, prime video, showtime, starz, sling tv, youtube, peacock
Smart Applications	amazon alexa, google assistant
Voice Assistant	amazon alexa, google assistant
Remote Control	voice control
3D	no
Power Consumption	286 kilowatt hours
Depth with Stand	14.5 inches
Height with Stand	40.25 inches
Width with Stand	67.87 inches
Net Weight with Stand	66.3 pounds
Depth without Stand	2.25 inches
Height without Stand	39.37 inches
Net Weight without Stand	63.7 pounds
