101
CX-JTD8
SECTION 8
ELECTRICAL PARTS LIST
CD KEY DRIVER
FRONT AMP
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1-689-685-11 CD KEY BOARD
*************
< CONNECTOR >
CN302 1-695-364-31 PIN, CONNECTOR (PC BOARD) 3P
< RESISTOR >
R15 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R16 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R17 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R18 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R19 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
< SWITCH >
S15 1-771-410-21 SWITCH, TACTILE (DISC CHANGE/DISC SKIP)
S16 1-771-410-21 SWITCH, TACTILE (DISC DIRECT PLAY 1)
S17 1-771-410-21 SWITCH, TACTILE (DISC DIRECT PLAY 2)
S18 1-771-410-21 SWITCH, TACTILE (DISC DIRECT PLAY 3)
S19 1-771-410-21 SWITCH, TACTILE (OPEN/CLOSE Z)
**************************************************************
1-687-135-11 DRIVER BOARD
*************
< CAPACITOR >
C715 1-126-933-11 ELECT 100uF 20% 16V
C731 1-126-964-11 ELECT 10uF 20% 50V
C735 1-164-159-11 CERAMIC 0.1uF 50V
C736 1-164-159-11 CERAMIC 0.1uF 50V
C737 1-164-159-11 CERAMIC 0.1uF 50V
C741 1-162-306-11 CERAMIC 0.01uF 30% 16V
C751 1-162-306-11 CERAMIC 0.01uF 30% 16V
C752 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-785-338-11 PIN, CONNECTOR (LIGHT ANGLE) 12P
CN702 1-784-766-11 CONNECTOR, FFC 5P
* CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D701 8-719-947-16 DIODE MTZJ-T-72-5.1A
D711 8-719-983-66 DIODE MTZJ-T-72-3.6B
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR RT1N141S-TP
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-417-11 CARBON 1K 5% 1/4W
R712 1-249-425-11 CARBON 4.7K 5% 1/4W
R713 1-249-433-11 CARBON 22K 5% 1/4W
R721 1-249-425-11 CARBON 4.7K 5% 1/4W
R722 1-249-425-11 CARBON 4.7K 5% 1/4W
R723 1-249-425-11 CARBON 4.7K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-249-417-11 CARBON 1K 5% 1/4W
R734 1-249-430-11 CARBON 12K 5% 1/4W
R735 1-247-807-31 CARBON 100 5% 1/4W
R751 1-249-425-11 CARBON 4.7K 5% 1/4W
**************************************************************
A-4749-160-A FRONT AMP BOARD, COMPLETE
**************************
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-162-294-31 CERAMIC 0.001uF 10% 50V
C203 1-162-286-31 CERAMIC 220PF 10% 50V
C204 1-126-967-11 ELECT 47uF 20% 50V
C206 1-136-495-11 FILM 0.068uF 5% 50V
C207 1-136-495-11 FILM 0.068uF 5% 50V
C208 1-128-560-11 ELECT 22uF 20% 100V
C216 1-162-306-11 CERAMIC 0.01uF 30% 16V
C221 1-128-562-11 ELECT 47uF 20% 100V
C222 1-126-968-11 ELECT 100uF 20% 50V
C231 1-126-964-11 ELECT 10uF 20% 50V
C232 1-104-665-11 ELECT 100uF 20% 10V
C233 1-126-961-11 ELECT 2.2uF 20% 50V
C234 1-104-665-11 ELECT 100uF 20% 10V
C235 1-164-159-11 CERAMIC 0.1uF 50V
•Abbreviation
EA : Saudi Arabia model
MY : Malaysia model
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
SP : Singapore model
To Next Page
