Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
116
CX-JTD8
C423 1-126-947-11 ELECT 47uF 20% 10V
C424 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C425 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C426 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C427 1-164-473-11 CERAMIC CHIP 820PF 5% 50V
C428 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C429 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C430 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C432 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C434 1-126-956-91 ELECT 0.1uF 20% 50V
C436 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C437 1-104-665-11 ELECT 100uF 20% 25V
C439 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C441 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C442 1-126-962-11 ELECT 3.3uF 20% 50V
C801 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C802 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C803 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C804 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C805 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C806 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C807 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C808 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN101 1-784-739-11 CONNECTOR, FFC 17P
CN105 1-784-731-11 CONNECTOR, FFC 9P
CN301 1-784-725-11 CONNECTOR, FFC 3P
< DIODE >
D191 8-719-988-61 DIODE 1SS355TE-17
D401 8-719-988-61 DIODE 1SS355TE-17
D403 8-719-069-55 DIODE UDZSTE-175.6B
< FERRITE BEAD >
FB401 1-414-760-21 FERRITE 0uH
< FLUORESCENT INDICATOR TUBE>
FL1001 1-518-918-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC101 6-802-994-01 IC uPD780232GC-082-8BT
IC102 8-759-584-98 IC SN74AHCT04NSR
IC401 8-759-710-97 IC NJM4565M (TE2)
IC402 6-702-896-01 IC BU9262AFS
IC802 6-600-174-01 IC RPM7240-H4
(REMOTE CONTROL RECEIVER)
< SHORT >
JR101 1-126-864-11 SHORT CHIP 0
JR102 1-126-864-11 SHORT CHIP 0
JR103 1-126-864-11 SHORT CHIP 0
JR105 1-126-864-11 SHORT CHIP 0
JR401 1-126-864-11 SHORT CHIP 0
JR402 1-126-864-11 SHORT CHIP 0
JR403 1-126-296-00 SHORT CHIP 0
JR404 1-126-864-11 SHORT CHIP 0
JR405 1-126-864-11 SHORT CHIP 0
< CAPACITOR >
JW408 1-126-962-11 ELECT 3.3uF 20% 50V
< COIL >
L401 1-469-186-51 INDUCTOR 82uH
< LED >
LED192 8-719-063-93 DIODE SLR325VC-N-T32 (1 STANDBY/ON)
LED205 8-719-063-93 DIODE SLR325VC-N-T32 (HEAVY)
LED206 8-719-063-93 DIODE SLR325VC-N-T32 (VOCAL)
LED207 8-719-063-93 DIODE SLR325VC-N-T32 (SALSA)
LED208 8-719-063-93 DIODE SLR325VC-N-T32 (TECHNO)
LED209 8-719-063-93 DIODE SLR325VC-N-T32 (HIP HOP)
LED210 8-719-063-93 DIODE SLR325VC-N-T32 (MANUAL)
LED211 8-719-063-93 DIODE SLR325VC-N-T32 (DVD)
LED212 8-719-063-93 DIODE SLR325VC-N-T32 (TUNER/BAND)
LED213 8-719-063-93 DIODE SLR325VC-N-T32 (TAPE A/B)
LED214 8-719-063-93 DIODE SLR325VC-N-T32 (MD (VIDEO))
LED215 8-719-063-93 DIODE SLR325VC-N-T32 (i-Bass)
< TRANSISTOR >
Q126 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q127 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q128 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q129 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q130 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q131 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q132 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q133 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q134 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q135 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q136 8-729-907-00 TRANSISTOR DTC114EUA-T106
Q168 8-729-028-97 TRANSISTOR DTC114TUA-T106
Q191 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q401 8-729-045-62 FET 2SK2158-T2B
< RESISTOR >
R11 1-216-817-11 METAL CHIP 470 5% 1/10W
R12 1-216-819-11 METAL CHIP 680 5% 1/10W
R13 1-216-821-11 METAL CHIP 1K 5% 1/10W
R14 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R31 1-216-817-11 METAL CHIP 470 5% 1/10W
R32 1-216-819-11 METAL CHIP 680 5% 1/10W
R33 1-216-821-11 METAL CHIP 1K 5% 1/10W
R34 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R35 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R36 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R37 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R38 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R39 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R40 1-216-833-11 METAL CHIP 10K 5% 1/10W
R51 1-216-817-11 METAL CHIP 470 5% 1/10W
R52 1-216-819-11 METAL CHIP 680 5% 1/10W
R53 1-216-821-11 METAL CHIP 1K 5% 1/10W
R54 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
MICON-KEY
