Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
121
CX-JTD8
< TERMINAL >
TM401 1-694-674-22 TERMINAL BOARD (6P)
(CENTER/SURROUND SPEAKER)
**************************************************************
1-687-669-11 SW BOARD
**********
< SWITCH >
S751 1-786-514-11 SWITCH, LEVER (SLIDE)
(OPEN/CLOSE DETECT)
**************************************************************
A-4749-162-A TRANS BOARD, COMPLETE
**********************
< CAPACITOR >
C271 1-130-777-00 MYLAR 0.1uF 5% 100V
C272 1-130-777-00 MYLAR 0.1uF 5% 100V
C371 1-136-153-00 FILM 0.01uF 5% 50V
C372 1-136-153-00 FILM 0.01uF 5% 50V
C912 1-126-960-11 ELECT 1uF 20% 50V
C913 1-126-968-11 ELECT 100uF 20% 50V
C915 1-164-159-11 CERAMIC 0.1uF 50V
C918 1-128-576-11 ELECT 100uF 20% 63V
C929 1-126-964-11 ELECT 10uF 20% 50V
C930 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN914 1-564-526-11 PLUG, CONNECTOR 11P
* CN915 1-566-313-11 PIN, CONNECTOR (3.96mm PITCH) 7P
< DIODE >
D271 6-500-250-01 DIODE D15XB20-4001
D371 8-719-510-68 DIODE D5SBA204101
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 8-759-983-75 DIODE MTZJ-T-72-27
D913 8-719-160-29 DIODE RD6.2F-T7B1
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932 (TP)
< RESISTOR >
0 R911 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
R914 1-249-429-11 CARBON 10K 5% 1/4W
R915 1-247-807-31 CARBON 100 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R917 1-249-393-11 CARBON 10 5% 1/4W
R938 1-249-429-11 CARBON 10K 5% 1/4W
< TRANSFORMER>
0 T911 1-443-047-11 TRANS, POWER
**************************************************************
A-4749-164-A VIDEO BOARD, COMPLETE
**********************
< CAPACITOR >
C800 1-126-935-11 ELECT 470uF 20% 6.3V
C801 1-162-306-11 CERAMIC 0.01uF 30% 16V
C802 1-126-960-11 ELECT 1uF 20% 50V
C804 1-126-960-11 ELECT 1uF 20% 50V
C806 1-126-960-11 ELECT 1uF 20% 50V
C807 1-104-665-11 ELECT 100uF 20% 10V
C808 1-162-306-11 CERAMIC 0.01uF 30% 16V
C810 1-164-159-11 CERAMIC 0.1uF 50V
C812 1-126-960-11 ELECT 1uF 20% 50V
C814 1-126-960-11 ELECT 1uF 20% 50V
C816 1-126-960-11 ELECT 1uF 20% 50V
C817 1-162-294-31 CERAMIC 0.001uF 10% 50V
C818 1-126-965-11 ELECT 22uF 20% 50V
C819 1-104-665-11 ELECT 100uF 20% 10V
C821 1-126-965-11 ELECT 22uF 20% 50V
C822 1-104-665-11 ELECT 100uF 20% 10V
C824 1-104-665-11 ELECT 100uF 20% 10V
C827 1-104-665-11 ELECT 100uF 20% 10V
C830 1-104-665-11 ELECT 100uF 20% 10V
C833 1-164-159-11 CERAMIC 0.1uF 50V
C840 1-162-282-31 CERAMIC 100PF 10% 50V
C841 1-126-935-11 ELECT 470uF 20% 6.3V
C851 1-126-934-11 ELECT 220uF 20% 10V
C852 1-126-964-11 ELECT 10uF 20% 50V
C860 1-126-942-61 ELECT 1000uF 20% 25V
C861 1-117-245-91 ELECT 330uF 20% 6.3V
C862 1-128-646-91 ELECT 1000uF 20% 6.3V
C863 1-117-317-91 ELECT 1000uF 20% 25V
C871 1-117-245-91 ELECT 330uF 20% 6.3V
C872 1-128-646-91 ELECT 1000uF 20% 6.3V
C873 1-117-317-91 ELECT 1000uF 20% 25V
C876 1-117-245-91 ELECT 330uF 20% 6.3V
C877 1-117-245-91 ELECT 330uF 20% 6.3V
< CONNECTOR >
CN801 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
* CN804 1-564-730-11 PIN, CONNECTOR (SMALL TYPE) 14P
< DIODE >
D838 8-719-991-33 DIODE 1SS133T-72
D861 8-719-210-21 DIODE 11EQS04-TA2B
D871 8-719-210-21 DIODE 11EQS04-TA2B
< GROUND TERMINAL >
EP802 1-537-771-21 TERMINAL BOARD, GROUND
< IC >
IC801 6-702-335-01 IC MM1568AJBE
IC803 8-759-231-53 IC TA7805S
IC804 8-759-659-28 IC SI-8033S
IC805 8-759-474-09 IC SI-8050S-LF1101
SURROUND AMP SW TRANS VIDEO
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
