Sony DCR-PC101 User Manual

— 2 —
DCR-PC101/PC101E
TABLE OF CONTENTS
4. PRINTED WIRING BOARDS AND
SCHEMATIC DIAGRAMS
4-2. Schematic Diagrams ························································4-5
VC-284 (1/20) (A/D CONVERTER,
TIMING GENERATOR) ················································4-9
VC-284 (2/20) (CAMERA PROCESSOR) ···················4-11
VC-284 (3/20) (FOCUS/ZOOM/IRIS/
ND FILTER DRIVE) ····················································4-13
VC-284 (4/20) (MPEG MOVIE/DIGITAL STILL
PROCESS) ····································································4-15
VC-284 (5/20) (HI CONTROL,
DIGITAL STILL CONTROL) ······································4-17
VC-284 (6/20) (FLASH MEMORY, SDRAM)·············4-19
VC-284 (7/20) (DV SIGNAL PROCESS) ····················4-21
VC-284 (8/20) (DV INTERFACE) ·······························4-23
VC-284 (9/20) REC/PB AMP) ······································4-25
VC-284 (10/20) (USB INTERFACE) ···························4-27
VC-284 (11/20) (VIDEO A/D CONVERTER) ·············4-29
VC-284 (12/20) (VIDEO IN/OUT)·······························4-31
VC-284 (13/20)
(EVF DRIVE, TIMING GENARATOR) ······················4-33
VC-284 (14/20)
(DRUM/CAPSTAN/LOADING DRIVE) ·····················4-35
VC-284 (15/20) (CAMERA/MECHA CONTROL) ·····4-37
VC-284 (16/20) (HI CONTROL) ··································4-39
VC-284 (17/20) (AUDIO IN/OUT) ······························4-41
VC-284 (18/20) (DC/DC CONVERTER) ·····················4-43
VC-284 (19/20) (CONNECTOR 1) ······························4-45
VC-284 (20/20) (CONNECTOR 2) ······························4-47
BJ-003 (DC IN, DV/USB CONNECTOR) ···················4-49
4-3. Printed Wiring Boards ···················································4-67
VC-284 ··········································································4-73
BJ-003 ···········································································4-77
4-4. Waveforms ·····································································4-98
4-5. Mounted Parts Location ··············································4-103
6. REPAIR PARTS LIST
6-2. Electrical Parts List ·······················································6-11
Section Title Page

Sony DCR-PC101 Specifications

General

Digital zoom	120 x
Optical zoom	10 x
Focal length range	3.7 - 37 mm
Sensor type	CCD
Total megapixels	1.07 MP
Optical sensor size	1/4.7 \
Display diagonal	2.5 \
Resolution	1152 x 864 pixels
Flash memory	8 MB
Horizontal resolution	520 lines
Minimum illumination	7 lx
Built-in microphone	Yes
