Sony DCR-PC101 User Manual

4-105
DCR-PC101/PC101E
COVER
COVER
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
BJ-003
BJ-003 BOARD
C001 A-6
* CN001 B-6
* CN002 B-5
CN003 A-6
CN004 A-5
* CN005 E-5
* CN006 A-2
CN007 A-2
* D001 A-6
* D002 A-5
* D003 B-6
D005 A-5
D006 A-2
* D007 E-5
* F001 E-5
* F002 E-5
* F003 E-5
* F004 E-6
* F005 E-5
* F006 E-4
* F007 A-5
LF001 A-5
LF002 A-6
Q001 A-6
Q002 A-6
* Q003 A-6
* Q004 A-6
Q005 A-6
* R001 E-6
* R003 A-5
R004 A-6
R005 A-6
* R008 A-6
* R011 A-6
* R012 A-6
R013 B-6
no mark : side A
* mark : side B

Sony DCR-PC101 Specifications

General

Digital zoom	120 x
Optical zoom	10 x
Focal length range	3.7 - 37 mm
Sensor type	CCD
Total megapixels	1.07 MP
Optical sensor size	1/4.7 \
Display diagonal	2.5 \
Resolution	1152 x 864 pixels
Flash memory	8 MB
Horizontal resolution	520 lines
Minimum illumination	7 lx
Built-in microphone	Yes
