Sony DSR-250P - Page 149

4-123
DSR-250/250P
WAVEFORMS
VI-156
VI-156 BOARD (7/25)
rf IC1301 rh REC
480mVp-p
H
400mVp-p
H
rg IC1301 rh PB
rh IC1301 7 REC
250mVp-p
H
400mVp-p
H
rj IC1301 7 PB
rk IC1301 ws REC
2.0Vp-p
H
rl IC1301 ws PB
2.0Vp-p
H
VI-156 BOARD (8/25)
t; IC903 2 LINE REC
1.0Vp-p
H
3.0Vp-p
74 nsec
ta IC903 yk REC/PB
VI-156 BOARD (9/25)
REC/PB
ts IC501 1 (C502)
1.2Vp-p
50 nsec
VI-156 BOARD (10/25)
REC/PB
td IC4300 w;
3.5Vp-p
185 msec
tf IC4300 wd
3.5Vp-p
105 msec
VI-156 BOARD (11/25)
REC/PB
th IC4500 4
3.2Vp-p
6.6 msec
tj IC4500 y;
3.0Vp-p
1.1 msec
tg IC4400 wf
3.0Vp-p
610 µsec
VI-156 BOARD (12/25)
tl IC102 ea,ed REC ONLY
y; IC102 eg
REC/PB
tk IC102 wj PB ONLY
400mVp-p
3.3 msec
2.0Vp-p
2.0Vp-p
6.6 msec
2.4Vp-p
23.8 nsec
ya IC102 r; REC ONLY
3.3 msec
VI-156 BOARD (13/25)
REC/PB
ys IC802 ra
800 mVp-p
50 nsec
VI-156 BOARD (17/25)
REC/PB
yf IC1104 td (R1203)
yd IC1104 r; (X1101)
3.8Vp-p
50 nsec
3.4Vp-p
30.5 µsec
