Help Guide
Wireless Microphone
ECM-W2BT
Specifications
Wireless communication
Receiver
Microphone (transmitter)
Communication system Bluetooth specification Ver. 5.0
Output Bluetooth specification Power Class 1
Main compatible Bluetooth Profile Advanced Audio Distribution Profile
Working range
*
Up to 200 m (600 ft.)
This is the approximate communication distance when the microphone is upright and directly facing the receiver. Depending on recording
location, such as if obstacles or reflective surfaces are between Bluetooth devices, radio wave conditions, etc.
*
Microphone
system
Monaural, non-directional
Frequency
response
20 Hz - 20,000 Hz
Power
requirements
Built-in lithium-ion battery (approx. 3.7 V) / Power supply via the Multi Interface Shoe
Power
consumption
Approx. 0.3 W
Continuous
operating time
Approx. 3 hours (with the fully charged built-in battery and with the analog audio output selected)
(approx. 18 hours with power supply via the Multi Interface Shoe)
Charging time Approx. 1 hour and 30 minutes (via a computer)
Operating
temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage
temperature
-20 °C to +45 °C (-4 °F to +113 °F)
Dimensions
(Approx.)
34 mm × 28.7 mm × 53 mm (1 3/8 in. × 1 3/16 in. × 2 1/8 in.) (W/H/D)
Mass (Approx.) 28 g (1.0 oz.)
Microphone system Monaural, non-directional
External microphone input jack Ø3.5 mm Stereo mini jack
Frequency response 20 Hz - 20,000 Hz
Power requirements Built-in lithium-ion battery (approx. 3.7 V)
