Sony EXMOR PMW-EX1 User Manual

Table of Contents
4
Overview
Package Configuration ............................................................. 9
Features .................................................................................... 10
Using the CD-ROM ................................................................ 12
Reading the CD-ROM Manuals ................................... 12
System Requirements for Using the Applications ....... 13
Software Installation .................................................... 13
Parts Identifications ................................................................ 14
Camcorder .................................................................... 14
IR Remote Commander (Supplied) .............................. 18
On-Screen Indications ............................................................ 19
Indications in Camera Mode ........................................ 19
Direct Menu Operation ................................................ 20
Preparations
Power Supply ........................................................................... 22
Using a Battery Pack .................................................... 22
Using AC Power (DC IN Power) ................................. 23
Turning Power On ........................................................ 24
Turning Power Off ....................................................... 24
Setting the Clock ..................................................................... 24
Adjusting the LCD Monitor and Viewfinder ....................... 25
Adjusting the LCD Monitor ......................................... 25
Adjusting the Viewfinder ............................................. 26
Adjusting the Grip .................................................................. 28
Using the IR Remote Commander ........................................ 28
Handling SxS Memory Cards ................................................ 30
About SxS Memory Cards ........................................... 30
Inserting/Removing an SxS Memory Card .................. 31
Switching Between SxS Memory Cards ...................... 32
Formatting an SxS Memory Card ................................ 32
Checking the Remaining Time Available for
Recording ............................................................... 33
Restoring an SxS Memory Card .................................. 33
Table of Contents

Sony EXMOR PMW-EX1 Specifications

General

Sensor Type	3x 1/2-inch Exmor CMOS
Lens	Fujinon 14x Zoom Lens
Media Type	SxS Memory Card
Maximum Aperture	f/1.9
Gain	-3, 0, 3, 6, 9, 12, 18 dB
Video Resolution	1920 x 1080, 1280 x 720
Microphone	Built-in stereo microphone
Recording Format	MPEG-2 Long GOP
LCD Screen	3.5-inch LCD
Viewfinder	0.45-inch color LCD
Audio	2-channel XLR inputs
Focal Length	5.8 to 81.2 mm
ND Filter	1/4, 1/16, 1/64
Shutter Speed	1/2 - 1/2000 sec
Memory Card Slot	2x SxS card slots
Video Output	HDMI, Composite
Frame Rate	23.98p, 25p, 29.97p, 50i
Input/Output	XLR audio inputs, Headphone output
