FCB-ER8550/CR8550(GB) D-201-100-12(1)
18
External synchronization function
(FCB-ER8550)
External synchronization will start when you input
synchronization signals to 15pin on CN1701.
The possible external synchronization combinations
are listed below:
Input External
Signal
format
Tri-State Sync
NTSC
Black
burst
PAL
Black
burst
1080/59.94i 1080/50i 1080/47.95i
Camera
Mode
3840×2160/29.97p

× ×

×
3840×2160/25p ×

× ×

3840×2160/23.98p × ×

× ×
1920×1080/59.94p

× ×

×
1920×1080/59.94i

× ×

×
1920×1080/50p ×

× ×

1920×1080/50i ×

× ×

1920×1080/29.97p

× ×

×
1920×1080/25p ×

× ×

1920×1080/23.98p × ×

× ×
1280×720/59.94p

× ×

×
1280×720/50p ×

× ×

720×480/59.94p

× ×

×
720×576/50p ×

× ×

External signal spec
• Tri-State SYNC: partial part of SMPTE 240M/274M
• NTSC Black burst: EBU N14/SMPTE RP-154/SMPTE
170M/SMPTE 318M
• PAL Black burst: ITU-R BT.470-6
The H Phase adoption function is not available.
Notes
• Once you input the external synchronization signal, do not
change the settings until the state enters the external
synchronization mode.
• If the external synchronization signal is not stable, the unit will
not enter the external synchronization mode.
• In the cases below, images or data will be disordered and may
malfunction.
– if you input signals other than the allowed external
synchronization signals.
– if you input external synchronization signals when the external
synchronization is not supported.
About the firmware
update
Overview
This document descries detailed operation for
firmware update.
Serial Port Setting during maintenance mode
Communication Speed 115200 bps
Data bit 8 bit
Parity None
Stop bit 1 bit
Flow control None
