FCB Camera Commands
Command List (1/7)
Command Set Command Command Packet Comments
AddressSet Broadcast 88 30 0p FF Address Setting p:Address
IF_Clear – 8x 01 00 01 FF I/F Clear
Broadcast 88 01 00 01 FF
CommandCancel – 8x 2p FF p: Socket No. (=1 or 2)
CAM_Power On 8x 01 04 00 02 FF Power On/Off
Off (Standby) 8x 01 04 00 03 FF
CAM_Zoom Stop 8x 01 04 07 00 FF –
Tele (Standard) 8x 01 04 07 02 FF
Wide (Standard) 8x 01 04 07 03 FF
Tele (Variable) 8x 01 04 07 2p FF p=0 (Low) to 7 (High)
Wide (Variable) 8x 01 04 07 3p FF
Direct 8x 01 04 47 0p 0q 0r 0s FF pqrs: Zoom Position
Min. 0000h
Max. 4000h (In Separate mode)
Max. 4000h (In Combine mode and DZoom=Off)
Max. 5556h (In Combine mode, DZoom=Super Resolution
Zoom, and monitoring mode QFHD)
Max. 6000h (In Combine mode, DZoom=Super Resolution
Zoom, and monitoring mode FHD or less)
Max. 7AC0h (In Combine mode and DZoom=On)
CAM_DZoom On 8x 01 04 06 02 FF Digital Zoom On/Off/Super Resolution Zoom
Off 8x 01 04 06 03 FF
Super Resolution Zoom 8x 01 04 06 04 FF
Combine Mode 8x 01 04 36 00 FF Optical/Digital Zoom Combined
Separate Mode 8x 01 04 36 01 FF Optical/Digital Zoom Separate
Stop 8x 01 04 06 00 FF –
Tele (Variable) 8x 01 04 06 2p FF p=0 (Low) to 7 (High)
* Enabled during Separate Mode
Wide (Variable) 8x 01 04 06 3p FF
x1/Max 8x 01 04 06 10 FF x1/MAX Magnification Switchover
* Enabled during Separate Mode
Direct 8x 01 04 46 00 00 0p 0q FF pq: D-Zoom Position (00h to EBh)
* Enabled during Separate Mode
CAM_Focus Mode Auto Focus 8x 01 04 38 02 FF AF On/Off
Manual Focus 8x 01 04 38 03 FF
Auto/Manual 8x 01 04 38 10 FF
CAM_Focus Stop 8x 01 04 08 00 FF –
Far (Standard) 8x 01 04 08 02 FF
Near (Standard) 8x 01 04 08 03 FF
Far (Variable) 8x 01 04 08 2p FF p=0 (Low) to 7 (High)
Near (Variable) 8x 01 04 08 3p FF
Direct 8x 01 04 48 0p 0q 0r 0s FF pqrs: Focus Position 0000h to F000h
One Push Trigger 8x 01 04 18 01 FF One Push AF Trigger
Near Limit 8x 01 04 28 0p 0q 0r 0s FF pqrs: Focus Near Limit Position 1000h to F000h
CAM_AFMode Normal AF 8x 01 04 57 00 FF AF Movement Mode
Interval AF 8x 01 04 57 01 FF
Zoom Trigger AF 8x 01 04 57 02 FF
Active/Interval Time 8x 01 04 27 0p 0q 0r 0s FF pq: Movement Time, rs: Interval
