SECTION 3
DISASSEMBLY
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
3-2. SIDE PANEL (L)/(R)
(Page 11)
3-3. PANEL (TOP)
(Page 11)
3-5. FRONT PANEL
BLOCK (EC78P: UK)
(Page 12)
(EC78P: UK)
3-6. FRONT PANEL BLOCK
(EC68P/EC78P: US, Canadian)
(Page 13)
(EC68P/EC78P: US, Canadian)
3-10. 1 CD MECHANISM BLOCK
(EC68P/EC78P: US, Canadian)
(Page 15)
3-11. BASE UNIT
(EC68P/EC78P: US, Canadian)
(Page 15)
3-12. BELT
(EC68P/EC78P: US, Canadian)
(Page 16)
3-13. BELT
(EC78P: UK)
(Page 16)
3-14. OP BASE ASSY
(KSM-213D)
(Page 17)
3-4. MAIN BOARD
(Page 12)
3-7. BACK PANEL
BLOCK
(Page 13)
3-8. 3 CD MECHANISM BLOCK
(EC78P: UK)
(Page 14)
3-14. OP BASE ASSY
(KSM-213D)
(Page 17)
3-9. BASE UNIT (EC78P: UK)
(Page 14)
SET
