HCD-FX200/FX205
7
2-6. MAIN BOARD
2-5. KNOB (VOL)
Note: This illustration sees the front panel block from PANEL board side.
2
knob (VOL)
hole
1
Push the knob (VOL)
by flat-head screwdriver.
front panel block
PANEL board
3
connector
(CN904)
1
connector (CN901)
7
MAIN board
4
two screws (BV3)
6
screw
(BVTP3
u
8)
2
connector
(CN902)
5
