50
HCD-GB3
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1177-469-A AMP BOARD, COMPLETE
********************
< CAPACITOR >
C201 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C202 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C203 1-126-963-11 ELECT 4.7uF 20% 50V
C204 1-126-963-11 ELECT 4.7uF 20% 50V
C205 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C206 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C209 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C210 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C211 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C212 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C244 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C251 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C252 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C253 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C254 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C901 1-126-963-11 ELECT 4.7uF 20% 50V
C902 1-126-967-11 ELECT 47uF 20% 50V
C903 1-126-967-11 ELECT 47uF 20% 50V
C921 1-126-963-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
CNP201 1-819-133-11 PIN, CONNECTOR
CNP202 1-815-446-11 PIN, CONNECTOR (PWB) 5P
CNP901 1-815-445-11 PIN, CONNECTOR (PWB) 4P
CNP902 1-819-131-11 PIN, CONNECTOR 3P
< DIODE >
D241 6-500-335-01 DIODE MC2838-T112-1
< IC >
IC202 6-709-529-01 IC STK432-070
< TRANSISTOR >
Q201 6-551-270-01 TRANSISTOR 2SA2026
Q202 6-551-270-01 TRANSISTOR 2SA2026
Q241 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q242 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q243 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q244 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q901 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q902 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q903 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
< RESISTOR >
R201 1-216-864-11 SHORT CHIP 0
R202 1-216-864-11 SHORT CHIP 0
R203 1-216-841-11 METAL CHIP 47K 5% 1/10W
R204 1-216-841-11 METAL CHIP 47K 5% 1/10W
R205 1-216-833-11 METAL CHIP 10K 5% 1/10W
R206 1-216-833-11 METAL CHIP 10K 5% 1/10W
R207 1-216-809-11 METAL CHIP 100 5% 1/10W
R208 1-216-809-11 METAL CHIP 100 5% 1/10W
R211 1-216-839-11 METAL CHIP 33K 5% 1/10W
R212 1-216-839-11 METAL CHIP 33K 5% 1/10W
R213 1-216-833-11 METAL CHIP 10K 5% 1/10W
R214 1-216-833-11 METAL CHIP 10K 5% 1/10W
R215 1-216-821-11 METAL CHIP 1K 5% 1/10W
R216 1-216-821-11 METAL CHIP 1K 5% 1/10W
R217 1-216-821-11 METAL CHIP 1K 5% 1/10W
R218 1-216-821-11 METAL CHIP 1K 5% 1/10W
R219 1-216-821-11 METAL CHIP 1K 5% 1/10W
R220 1-216-821-11 METAL CHIP 1K 5% 1/10W
R221 1-216-837-11 METAL CHIP 22K 5% 1/10W
R222 1-216-837-11 METAL CHIP 22K 5% 1/10W
R223 1-216-833-11 METAL CHIP 10K 5% 1/10W
R224 1-216-833-11 METAL CHIP 10K 5% 1/10W
R225 1-216-837-11 METAL CHIP 22K 5% 1/10W
R226 1-216-837-11 METAL CHIP 22K 5% 1/10W
R227 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R228 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R231 1-216-813-11 METAL CHIP 220 5% 1/10W
R232 1-216-813-11 METAL CHIP 220 5% 1/10W
R233 1-216-833-11 METAL CHIP 10K 5% 1/10W
R234 1-216-833-11 METAL CHIP 10K 5% 1/10W
0R235 1-216-361-31 METAL OXIDE 0.22 5% 2W
0R236 1-216-361-31 METAL OXIDE 0.22 5% 2W
0R237 1-216-361-31 METAL OXIDE 0.22 5% 2W
0R238 1-216-361-31 METAL OXIDE 0.22 5% 2W
R241 1-216-833-11 METAL CHIP 10K 5% 1/10W
R242 1-216-833-11 METAL CHIP 10K 5% 1/10W
R243 1-216-821-11 METAL CHIP 1K 5% 1/10W
R244 1-216-845-11 METAL CHIP 100K 5% 1/10W
R245 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R246 1-216-833-11 METAL CHIP 10K 5% 1/10W
R247 1-216-853-11 METAL CHIP 470K 5% 1/10W
R248 1-216-833-11 METAL CHIP 10K 5% 1/10W
R249 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R251 1-216-809-11 METAL CHIP 100 5% 1/10W
R252 1-216-809-11 METAL CHIP 100 5% 1/10W
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
•Abbreviation
AR : Argentine model
E2 : 120V AC area in E model
MX : Mexican model
