7
HCD-GB3
4
two screws
(+BV3
×
10
)
9
Remove the top panel section
in the direction of the arrow.
7
connector
(CNP502)
8
connector
(CNP501)
6
two claws
5
two dowels
1
screw
(+KTP3
×
10
)
2
screw
(+KTP3
×
10
)
3
three screws
(+BV3
×
10
)
3-2. SIDE PANEL (R), SIDE PANEL (L)
3-3. TOP PANEL SECTION
3
side panel (R)
6
side panel (L)
5
two screws
(+BV3
×
10
)
2
two screws
(+BV3
×
10
)
1
four screws
(case 3 TP2)
4
four screws
(case 3 TP2)
Note: Follow the disassembly procedure in the numerical order given.
