54
HCD-GB3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C873 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
< FILTER >
CF801 1-795-426-11 FILTER, CERAMIC (107MHz)
CF802 1-579-554-21 FILTER, CERAMIC (107MHz)
CF803 1-781-962-21 FILTER, CERAMIC (450kHz)
< CONNECTOR >
CNP151 1-819-136-11 PIN, CONNECTOR 8P
CNP171 1-815-449-11 PIN, CONNECTOR (PWB) 8P
CNP501 1-815-447-11 PIN, CONNECTOR (PWB) 6P
CNP502 1-815-444-11 PIN, CONNECTOR (PWB) 3P
* CNP802 1-506-680-11 PLUG, CONNECTOR (2.5MM) 3P
(ANTENNA FM/AM)
CNS104 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
CNS111 1-779-297-11 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
< DIODE >
D107 6-501-046-01 DIODE 1N5402-F46
D108 6-501-046-01 DIODE 1N5402-F46
D109 6-501-046-01 DIODE 1N5402-F46
D110 6-501-046-01 DIODE 1N5402-F46
D111 8-719-063-79 DIODE 1N4002B
D113 8-719-063-79 DIODE 1N4002B
D131 8-719-063-79 DIODE 1N4002B
D132 8-719-000-07 DIODE MC2836
D154 6-500-335-01 DIODE MC2838-T112-1
D156 8-719-000-07 DIODE MC2836
D191 8-719-063-79 DIODE 1N4002B
D192 8-719-063-79 DIODE 1N4002B
D193 6-501-164-01 DIODE UDZW-TE17-3.9B
D501 6-500-848-01 DIODE MC2840-T112-1
D502 6-500-848-01 DIODE MC2840-T112-1
D503 6-500-848-01 DIODE MC2840-T112-1
D504 6-500-848-01 DIODE MC2840-T112-1
D505 6-500-848-01 DIODE MC2840-T112-1
D506 6-500-848-01 DIODE MC2840-T112-1
D508 6-501-193-01 DIODE 1SS355WTE-17
D510 6-501-193-01 DIODE 1SS355WTE-17
D511 6-501-193-01 DIODE 1SS355WTE-17
D802 6-501-369-01 DIODE SV230-TB-E
D803 6-501-369-01 DIODE SV230-TB-E
D812 8-719-062-51 DIODE 1PS226-115
D813 8-719-062-51 DIODE 1PS226-115
D814 8-719-062-51 DIODE 1PS226-115
D851 6-501-142-01 DIODE SVC347A-TL-E
D901 6-500-335-01 DIODE MC2838-T112-1
< IC >
IC401 6-702-895-01 IC BD3881FV
IC402 8-759-909-71 IC BA4558F-E2
IC801 6-708-840-01 IC LV23003VA
< JACK >
J101 1-536-708-81 TERMINAL BOARD, PUSH (4P)
(SPEAKER IMPEDANCE 6Ω)
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
JR104 1-216-864-11 SHORT CHIP 0
JR105 1-216-864-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR107 1-216-864-11 SHORT CHIP 0
JR108 1-216-864-11 SHORT CHIP 0
JR109 1-216-864-11 SHORT CHIP 0
JR110 1-216-864-11 SHORT CHIP 0
JR801 1-216-864-11 SHORT CHIP 0
JR802 1-216-864-11 SHORT CHIP 0
JR803 1-216-864-11 SHORT CHIP 0
< COIL >
L101 1-456-107-11 COIL, AIR-CORE
L102 1-456-107-11 COIL, AIR-CORE
L501 1-456-094-11 TRANSFORMER, BIAS OSCILLATION
L803 1-433-741-11 TRANSFORMER, IF
L804 1-457-163-11 COIL, AIR-CORE
L805 1-457-162-11 COIL, AIR-CORE
L806 1-457-168-11 COIL, DET
L851 1-457-161-11 COIL, AM ANTENNA
L852 1-456-596-11 COIL, MW OSC
< TRANSISTOR >
Q102 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q121 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q122 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q131 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q132 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q133 8-729-027-38 TRANSISTOR RT1P441C-TP-1
Q134 1-801-806-11 TRANSISTOR RT1N441C-TP-1
Q135 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q137 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q138 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q151 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q152 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q153 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q154 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q191 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q192 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q193 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q501 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q502 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q507 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q508 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q801 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q802 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q803 6-550-304-01 TRANSISTOR 2SC5477-T122-1
< RESISTOR >
R101 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R103 1-216-841-11 METAL CHIP 47K 5% 1/10W
R104 1-216-841-11 METAL CHIP 47K 5% 1/10W
R105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R106 1-216-837-11 METAL CHIP 22K 5% 1/10W
MAIN
