57
HCD-GB3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< SWITCH >
SW501 1-762-369-11 SWITCH, SLIDE (a/H)
< CABLE HOLDER >
WH101 1-824-030-21 HOLDER, CABLE 5P
WH102 1-824-030-21 HOLDER, CABLE 5P
WH203 1-824-027-21 HOLDER, CABLE 3P
WH901 1-824-029-21 HOLDER, CABLE 4P
< VIBRATOR >
X801 1-767-388-21 VIBRATOR, CRYSTAL (75kHz)
*************************************************************
A-1177-458-A PANEL BOARD, COMPLETE (E2)
A-1177-460-A PANEL BOARD, COMPLETE (MX)
A-1177-461-A PANEL BOARD, COMPLETE (AR)
**********************
2-669-704-01 GUIDE, LCD
< CAPACITOR >
C671 1-126-965-91 ELECT 22uF 20% 50V
C672 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C701 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C702 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C703 1-124-584-00 ELECT 100uF 20% 10V
C704 1-119-941-91 ELECT 470uF 20% 6.3V
C705 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C706 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C707 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C708 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C709 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C710 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C711 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C712 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C713 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C714 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C715 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C716 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C717 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C718 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C719 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C721 1-126-925-91 ELECT 470uF 20% 10V
C722 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C723 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C724 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C725 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C726 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C727 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C728 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C729 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C730 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C731 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C732 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C733 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C734 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C735 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C736 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C737 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C738 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C739 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C741 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C742 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C743 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C746 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C747 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C750 1-126-963-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
CNS671 1-784-735-11 CONNECTOR, FFC 13P
CNS701 1-779-297-11 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
< DIODE >
D509 6-501-193-01 DIODE 1SS355WTE-17
D701 6-501-163-01 DIODE UDZW-TE17-3.6B
D702 8-719-000-07 DIODE MC2836
< IC >
IC701 6-806-467-01 IC MB90802PF-G-113E1
IC702 6-704-046-01 IC BU2099FV
IC703 6-600-446-01 IC RPM7240-H18
< JUMPER RESISTOR >
JR701 1-216-864-11 SHORT CHIP 0
JR702 1-216-864-11 SHORT CHIP 0
JR703 1-216-864-11 SHORT CHIP 0
JR704 1-216-864-11 SHORT CHIP 0
JR705 1-216-864-11 SHORT CHIP 0
JR706 1-216-864-11 SHORT CHIP 0
JR707 1-216-864-11 SHORT CHIP 0
JR708 1-216-864-11 SHORT CHIP 0
JR709 1-216-864-11 SHORT CHIP 0
JR710 1-216-864-11 SHORT CHIP 0
JR711 1-216-864-11 SHORT CHIP 0
JR712 1-216-864-11 SHORT CHIP 0
JR713 1-216-864-11 SHORT CHIP 0
JR714 1-216-864-11 SHORT CHIP 0
JR715 1-216-864-11 SHORT CHIP 0
JR716 1-216-864-11 SHORT CHIP 0
JR717 1-216-864-11 SHORT CHIP 0
JR718 1-216-864-11 SHORT CHIP 0
JR719 1-216-864-11 SHORT CHIP 0
JR720 1-216-864-11 SHORT CHIP 0
< COIL >
L701 1-216-864-11 SHORT CHIP 0
< LIQUID CRYSTAL DISPLAY >
LCD702 1-805-973-21 DISPLAY PANEL, LIQUID CRYSTAL
< LED >
LED701 6-501-479-01 DIODE 1L0341Y23E0CA602 (BACKLIGHT)
LED702 8-719-060-44 DIODE SLR-342VRT32 (STANDBY)
LED703 6-501-452-01 DIODE 1L4345V22DOTDT02 (VOLUME)
LED704 6-501-452-01 DIODE 1L4345V22DOTDT02 (VOLUME)
PANELMAIN
