71
HCD-RV7/RV8
SECTION 9
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BD CD OPEN
A-4728-371-A BD BOARD, COMPLETE
*******************
< CAPACITOR/SHORT >
C101 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C108 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C109 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-126-607-11 ELECT CHIP 47uF 20% 4V
C112 1-126-607-11 ELECT CHIP 47uF 20% 4V
C113 1-126-209-11 ELECT CHIP 100uF 20% 4V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C117 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C118 1-115-156-11 CERAMIC CHIP 1uF 10V
C119 1-115-156-11 CERAMIC CHIP 1uF 10V
C120 1-126-607-11 ELECT CHIP 47uF 20% 4V
C151 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C153 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C163 1-128-995-21 ELECT CHIP 100uF 20% 10V
C164 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C165 1-124-779-00 ELECT CHIP 10uF 20% 16V
C166 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C182 1-128-995-21 ELECT CHIP 100uF 20% 10V
C213 1-216-864-11 SHORT CHIP 0
< CONNECTOR >
CN101 1-784-877-21 CONNECTOR, FFC (LIF (NON-ZIF)) 28P
CN102 1-794-424-11 CONNECTOR, FCC/FPC 16P
< DIODE >
D101 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC102 8-759-713-70 IC AN41020A
IC103 8-752-089-74 IC CXA2581N-T4
< TRANSISTOR >
Q101 8-729-049-31 TRANSISTOR 2SB710A-RTX
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
Q102 8-729-424-08 TRANSISTOR UN2111
< RESISTOR >
R102 1-216-835-11 METAL CHIP 15K 5% 1/10W
R103 1-216-845-11 METAL CHIP 100K 5% 1/10W
R104 1-216-835-11 METAL CHIP 15K 5% 1/10W
R105 1-216-821-11 METAL CHIP 1K 5% 1/10W
R109 1-216-845-11 METAL CHIP 100K 5% 1/10W
R111 1-216-846-11 METAL CHIP 120K 5% 1/10W
R112 1-216-864-11 SHORT CHIP 0
R113 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R114 1-216-841-11 METAL CHIP 47K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-864-11 SHORT CHIP 0
R120 1-216-846-11 METAL CHIP 120K 5% 1/10W
R122 1-216-845-11 METAL CHIP 100K 5% 1/10W
R123 1-216-797-11 METAL CHIP 10 5% 1/10W
R124 1-216-797-11 METAL CHIP 10 5% 1/10W
R125 1-216-839-11 METAL CHIP 33K 5% 1/10W
R126 1-216-839-11 METAL CHIP 33K 5% 1/10W
R151 1-216-845-11 METAL CHIP 100K 5% 1/10W
R152 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R176 1-216-864-11 SHORT CHIP 0
R179 1-216-833-11 METAL CHIP 10K 5% 1/10W
R227 1-216-845-11 METAL CHIP 100K 5% 1/10W
R228 1-216-853-11 METAL CHIP 470K 5% 1/10W
R229 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R231 1-216-821-11 METAL CHIP 1K 5% 1/10W
R234 1-216-864-11 SHORT CHIP 0
R235 1-216-821-11 METAL CHIP 1K 5% 1/10W
R236 1-216-821-11 METAL CHIP 1K 5% 1/10W
**************************************************************
1-683-538-11 CD OPEN BOARD
**************
< RESISTOR >
R792 1-249-439-11 CARBON 68K 5% 1/4W
< SWITCH >
S792 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE Z)
**************************************************************
•Abbreviation
EA : Saudi Arabia model
MY : Malaysia model
SP : Singapore model
TH : Thai model
