HCD-SBT100/SBT100B/SBT300W/SBT300WB
7
FL, HP, KEY BOARDS SERVICE POSITION
MAIN, POWER BOARDS SERVICE POSITION
insulating sheet
ILLUMI board
KEY board
USB board
FL board
HP board
MAIN board
POWER board
