3-3. FRONT PANEL ASSY
3-4. TAPE MECHANISM DECK (CFP42601)
1
flexible flat cable (7 core)
(CN1304)
3
flexible flat cable (11core)
(CN1303)
4
flexible flat cable (9 core)
(CN1306)
5
flexible flat cable (11 core) (SPZ50)
flexible flat cable (17 core) (SPZ70)
(CN1305)
6
four
screws (B3)
7
front panel assy
2
connector
(CN1307)
2
four
screw
(2.6
×
8)
3
Tape mechanical deck
(CFP42601)
1
connector
(CN302)
