– 25 –
CD LID ASS’Y SECTION
6
four screws
(BVTP2.6
×
8)
7
CD lid ass’y
4
connector
(CN661)
2
four screws
(BVTP2.6
×
8)
3
CD-B1 SW board
1
connector
(CN642)
5
connector
(CN671)
PANEL (A) / (B) SUB ASS’Y
2
four screws
(BVTP2.6
×
8)
3
two claws
4
panel (A) sub ass’y
5
two claws
6
panel (B) sub ass’y
1
connector
(CN612)
