– 97 –
2
1
3
1
6
5
4
#3
#1
#1
#2
#2
#1
UK
Ref. No. Part No. Description Remark
1 4-929-973-01 SCREW (CASE, 3 POINT)
* 2 4-987-052-11 CASE
* 3 4-987-044-01 PANEL, BACK (AEP, UK)
* 3 4-987-044-21 PANEL, BACK (EE, CIS)
Ref. No. Part No. Description Remark
4 4-956-370-12 BAND, PLUG FIXED (UK)
* 5 A-4303-570-A TCB BOARD, COMPLETE (EE, CIS)
* 5 A-4303-576-A TCB BOARD, COMPLETE (AEP, UK)
6 1-773-006-11 WIRE (FLAT TYPE) (15 CORE)
SECTION 7
EXPLODED VIEWS
#2
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearrance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
• Abbreviation
EE: East European
(1) CASE, REAR PANEL SECTION
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference num-
ber in the exploded views are not supplied.
• Hardware (# mark) list and accessories and
packing materials are given in the last of the
electrical parts list.
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
