Sony HT-S350 User Manual

35
GB
Specifications
Amplifier section
POWER OUTPUT (rated)
Front L + Front R: 45 W + 45 W (at
4 ohms, 1 kHz, 1% THD)
POWER OUTPUT (reference)
Front L/Front R speaker: 85 W (per
channel at 4 ohms, 1 kHz)
Inputs
TV IN (OPTICAL)
Outputs
HDMI OUT (TV (ARC))
BLUETOOTH section
Communication system
BLUETOOTH Specification version 5.0
Output
BLUETOOTH Specification Power
Class 1
Maximum communication range
Line of sight approx. 25 m
1)
Frequency band
2.4 GHz band (2.4000 GHz -
2.4835 GHz)
Maximum output power
< 9 dBm
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profiles
2)
A2DP (Advanced Audio Distribution
Profile)
AVRCP (Audio Video Remote Control
Profile)
Supported Codec
3)
SBC
4)
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling frequency
32 kHz, 44.1 kHz, 48 kHz)
1)
The actual range will vary depending on
factors such as obstacles between
devices, magnetic fields around a
microwave oven, static electricity,
cordless phone use, reception
sensitivity, the operating system,
software applications, etc.
2)
BLUETOOTH standard profiles indicate
the purpose of BLUETOOTH
communication between devices.
3)
Codec: Audio signal compression and
conversion format
4)
Abbreviation for Subband Codec
Front L/Front R speaker block section
Speaker system
2 Speaker System
Speaker
Front L/Front R speaker: 52 mm ×
90 mm cone type, 4 Ω
General
Power requirements
220 V - 240 V AC, 50 Hz/60 Hz
Power consumption
On: 30 W
Standby mode: 0.5 W or less (Power
Saving mode)
(When Control for HDMI function and
BLUETOOTH Standby mode are set to
off)
Standby mode: 2 W or less*
(When Control for HDMI function and
BLUETOOTH Standby mode are set to
on)
* The Sound Bar will automatically
enter Power saving mode when
there is no HDMI connection and no
BLUETOOTH pairing history.
Dimensions* (approx.) (w/h/d)
900 mm × 64 mm × 88 mm
* Not including projection portion
Mass (approx.)
2.4 kg
POWER OUTPUT (reference)
150 W (at 2.5 ohms, 100 Hz)
Speaker system
Subwoofer speaker system, Bass
reflex
Additional Information
Bar Speaker (SA-S350)
Subwoofer (SA-WS350)

Sony HT-S350 Specifications

General

Audio decoders	Dolby Digital, Dolby Dual Mono
RMS rated power	320 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Soundbar speaker RMS power	- W
Bluetooth version	5.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Woofer diameter (subwoofer)	6.3 \
Cables included	Optical
Receiver included	-
FM radio	No
Product color	Black
Apple docking compatibility	Not supported
Soundbar power consumption	30 W
Subwoofer power consumption	25 W
Harmonized System (HS) code	85182200

Weight and Dimensions

Depth	88 mm
Width	900 mm
Height	64 mm
Soundbar weight	2400 g
Subwoofer depth	390 mm
Subwoofer width	190 mm
Subwoofer height	382 mm
Subwoofer weight	7800 g
