Sony ICF-C212 User Manual

ICF-C212
13
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
AUS : Australian
SP : Singapore
When indicating parts by reference num-
ber, please include the board.
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
* A-3347-801-A MAIN BOARD, COMPLETE (SP)
* A-3663-943-A MAIN BOARD, COMPLETE (AUS)
*******************
3-044-220-01 HOLDER (ANT)
< FILTER, BAND PASS >
BPF1 1-236-022-11 FILTER, BAND PASS
< CAPACITOR >
C2 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C3 1-163-103-00 CERAMIC CHIP 27PF 5% 50V
C4 1-162-934-11 CERAMIC CHIP 3PF 0.25PF 50V
C5 1-126-947-11 ELECT 47uF 20% 10V
C6 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C7 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C8 1-126-960-11 ELECT 1uF 20% 50V
C9 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C10 1-126-963-11 ELECT 4.7uF 20% 50V
C11 1-126-964-11 ELECT 10uF 20% 50V
C12 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C14 1-126-947-11 ELECT 47uF 20% 10V
C15 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C16 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C17 1-104-665-11 ELECT 100uF 20% 10V
C18 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C19 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C20 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C21 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C22 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C23 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C24 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C25 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C26 1-126-934-11 ELECT 220uF 20% 16V
C27 1-126-916-11 ELECT 1000uF 20% 6.3V
C28 1-126-916-11 ELECT 1000uF 20% 6.3V
C31 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C32 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C33 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< FILTER >
CF1 1-781-790-11 FILTER, AM CERAMIC
CF2 1-781-861-71 FILTER, CERAMIC (COMBINATION)
CF3 1-781-861-71 FILTER, CERAMIC (COMBINATION)
< TRIMMER >
CT1 1-141-620-11 (AM TRAKING)
CT2 1-141-620-11 (FM TRAKING)
CT3 1-141-620-11 (FM FREQUENCY COVERAGE)
CT4 1-141-620-11 (AM FREQUENCY COVERAGE)
< VARIABLE CAPACITOR >
CV1 1-141-620-11 CAP, VAR (TUNIG)
CV2 1-141-620-11 CAP, VAR (TUNIG)
CV3 1-141-620-11 CAP, VAR (TUNIG)
CV4 1-141-620-11 CAP, VAR (TUNIG)
< DIODE >
D1 8-719-911-19 DIODE 1SS119-25
D2 8-719-911-19 DIODE 1SS119-25
D3 8-719-911-19 DIODE 1SS119-25
D4 8-719-911-19 DIODE 1SS119-25
D5 8-719-911-19 DIODE 1SS119-25
D6 8-719-052-88 DIODE 1N4002
D7 6-500-078-01 DIODE COG309T0E1 (SP)
D7 6-500-077-01 DIODE COG309T0A1 (AUS)
< IC >
IC1 8-752-037-02 IC CXA1019S
IC2 8-759-821-46 IC LM8560N
< COIL >
L1 1-419-532-41 COIL, FERRITE-ROD ANTENNA (MW)
(AM TRAKING)
* L2 1-422-320-11 COIL, AIR-CORE (FM TRAKING)
L3 1-422-131-00 COIL, FM OSCILLATION
(FM FREQUENCY COVERAGE)
L4 1-419-533-21 COIL, OSCILLATION (MW)
< TRANSISTOR >
Q1 8-729-010-05 TRANSISTOR MSB709-RT1
< RESISTOR >
R1 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2 1-216-805-11 METAL CHIP 47 5% 1/10W
R3 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4 1-216-849-11 METAL CHIP 220K 5% 1/10W
R5 1-216-813-11 METAL CHIP 220 5% 1/10W
R6 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R7 1-216-837-11 METAL CHIP 22K 5% 1/10W

Sony ICF-C212 Specifications

General

Display type	LED
Radio type	Clock
Tuner type	Analog
