Specifications
Specifications
The following specifications show the reference
performance for this unit and individual option boards.
Design and specifications are subject to change without
notice.
MKS-8700 Device Control Unit
General
Power requirements
100 to 240 V AC, 50/60 Hz
Peak inrush current
(1) Power ON, current probe method:
20 A (100 V), 70 A (240 V)
(2) Hot switching inrush current,
measured in accordance with
European standard EN55103-1: 45 A
(230 V)
Power consumption
1.4 A to 0.8 A
Operating temperature
5ºC to 40ºC (41ºF to 104ºF)
Performance guranteed temperature
10ºC to 35ºC (50ºF to 95ºF)
Storage temperature
−20ºC to +60ºC (−4ºF to +140ºF)
Operating humidity
10% to 90%
Dimensions (w/h/d, excluding projections)
440 × 132 × 520 mm
(17
3
/
8
× 5
1
/
4
× 20
1
/
2
inches)
Mass Approx. 13 kg (28 lb 10 oz)
(without MKS-8701 and MKS-8702)
Reference input
REF IN BNC type, 75Ω, with loop-through
output
HDTV systems:
HD tri-level sync/SDTV analog black
burst/SDTV analog sync
SDTV systems:
Analog black burst/analog sync
Control connectors
PERIPH RJ-45
Complies with 100Base-TX standard
SERIAL TALLY 1, 2
D-sub 9-pin, female
Complies with RS-422A standard
Data transfer rate: 38.4 Kbps
TALLY/GPI IN 1 to 34, 35 to 68, 69 to 102
D-sub 37-pin, female
TTL inputs: 34
AC input
AC IN A, B 3-pin AC connector
Accessories supplied
75Ω terminator (1)
Operation Manual (1)
Installation Manual (1)
Accessories not supplied
AC power cord (for USA and Canada only) (125 V 10 A
2.4 m (8 ft)) (Part No.: 1-557-377-11)
AC power cord (for Europe only) (250 V 10 A 2.4 m
(8 ft)) (Part No.: 1-782-929-21)
MKS-8701 TALLY/GPI Output Board
General
Power requirements
12 V DC
Power consumption
Max. 1 A
Dimensions (w/d)
RC board: 317 × 380 mm
(12
1
/
2
× 15 inches)
CN board: 278 × 94 mm
(11 × 3
3
/
4
inches)
Mass Approx. 1.2 kg (2 lb 10 oz)
Output connectors
TALLY/GPI OUT 1 to 18, 19 to 36, 37 to 54
D-sub 37-pin, female
Relay contact outputs: 18 (30 V AC/DC,
0.1 A)
Accessories supplied
Operation and Installation Guide (1)
(supplied only when product is purchased separately)
Note
Always verify that the unit is operating properly before
use. SONY WILL NOT BE LIABLE FOR DAMAGES OF
ANY KIND INCLUDING, BUT NOT LIMITED TO,
COMPENSATION OR REIMBURSEMENT ON
ACCOUNT OF THE LOSS OF PRESENT OR
PROSPECTIVE PROFITS DUE TO FAILURE OF THIS
UNIT, EITHER DURING THE WARRANTY PERIOD OR
AFTER EXPIRATION OF THE WARRANTY, OR FOR
ANY OTHER REASON WHATSOEVER.
