– 10 –
3-7. CABINET (SV) ASSY
3-8. OP BLOCK ASSY
1
MD, step
2
MD, step
4
cabinet (SV) ass
y
3
mechanism block assy
1
M1.4x3.0 locking
3
shaft, mai
n
4
flexible board
adhesive sheet
OP block assy
2
M1.4x3.0
