16
Operation
These sections describe how to select and make
adjustments to the sound fields.
For details concerning sound fields, please refer to the
operating instructions supplied with the receiver.
Displaying the SOUND FIELD screen
Touch SOUND FIELD.
The SOUND FIELD screen appears.
The SOUND FIELD screen hierarchy is shown below.
SOUND FIELD screen hierarchy
Selecting Sound Fields
SOUND FIELD
Selecting the sound field
For details concerning which sound fields can be selected,
please refer to the receiver’s operating instructions.
1 Touch SOUND FIELD.
The SOUND FIELD screen appears.
2 Use the JOG DIAL or touch $ or 4 to scroll through
the list.
3 Push the jog dial to select the highlighted sound
field or touch the sound field you desire.
A check (✔) will appear next to the selected sound
field, and the sound field will change.
Selected
sound field
Turns the sound field on or off with each touch
Cursor
Genre of
sound field
highlighted
by the cursor

Sony RM-TP501 Primary Specifications

Display

liquid crystal size	3.8 inches
display resolution	256 x 200 dots
liquid crystal type	Reflection system (Monochrome type)

Power

power requirements for operation	DC 6V (Type AA alkaline batteries)
power requirements for memory preservation	DC 3V (CR2032 lithium battery)

Weight and Dimensions

maximum external dimensions	160 x 111 x 46 mm
mass	290 g (Main unit only including touch pen)
