Sony RM-TP501 Primary User Manual

3
TABLE OF CONTENTS
Preparations 4
Compatible Components and Functions 4
Preparing the Commander 5
Screen Hierarchy 8
Location of Parts and Basic
Operations 9
Front panel 9
Rear panel 10
Operation 11
Basic Operations 11
Example: Operating a CD Player 13
Example: Operating the Tuner 14
Example: Recording from CD to MD 15
Selecting Sound Fields 16
Adjusting Sound Fields 17
Adjusting the Commander’s Operating
Environment 18
Additional information 22
Precautions during use 22
Troubleshooting 23
Specifications Back Cover
Index Back Cover

Sony RM-TP501 Primary Specifications

Display

liquid crystal size	3.8 inches
display resolution	256 x 200 dots
liquid crystal type	Reflection system (Monochrome type)

Power

power requirements for operation	DC 6V (Type AA alkaline batteries)
power requirements for memory preservation	DC 3V (CR2032 lithium battery)

Weight and Dimensions

maximum external dimensions	160 x 111 x 46 mm
mass	290 g (Main unit only including touch pen)
