SA-WMS356/WMS556
SECTION 3
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CONTROL BOARD
**************
< CONNECTOR >
BC601 1-691-769-11 PLUG (MICRO CONNECTOR) 7P
BC602 1-564-505-11 PLUG, CONNECTOR 2P
< CAPACITOR >
C601 1-102-978-00 CERAMIC 220PF 5% 50V
C602 1-126-964-11 ELECT 10uF 20% 50V
C603 1-126-964-11 ELECT 10uF 20% 50V
C604 1-136-165-00 FILM 0.1uF 5% 50V
C605 1-136-165-00 FILM 0.1uF 5% 50V
C606 1-126-964-11 ELECT 10uF 20% 50V
C607 1-164-159-11 CERAMIC 0.1uF 50V
C608 1-126-964-11 ELECT 10uF 20% 50V
C609 1-164-159-11 CERAMIC 0.1uF 50V
C610 1-131-698-31 FILM 0.33uF 5% 50V
C611 1-131-695-11 FILM 0.18uF 5% 50V
C612 1-131-696-11 FILM 0.22uF 5% 50V
C613 1-131-696-11 FILM 0.22uF 5% 50V
C614 1-126-963-11 ELECT 4.7uF 20% 50V
C615 1-131-696-11 FILM 0.22uF 5% 50V
C616 1-131-688-31 FILM 0.047uF 5% 50V
C617 1-126-965-11 ELECT 22uF 20% 50V
C618 1-126-963-11 ELECT 4.7uF 20% 50V
C619 1-126-965-11 ELECT 22uF 20% 50V
< IC >
IC601 8-759-943-94 IC BA15218
IC602 8-759-943-94 IC BA15218
IC603 8-759-943-94 IC BA15218
IC604 8-759-943-94 IC BA15218
< JACK >
J601 1-815-025-11 JACK, PIN 1P (INPUT)
< TRANSISTOR >
Q601 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R601 1-247-831-11 CARBON 1K 5% 1/4W
R602 1-247-831-11 CARBON 1K 5% 1/4W
R603 1-247-879-11 CARBON 100K 5% 1/4W
R604 1-249-415-11 CARBON 680 5% 1/4W
R605 1-247-847-11 CARBON 4.7K 5% 1/4W
R606 1-247-847-11 CARBON 4.7K 5% 1/4W
R607 1-249-429-11 CARBON 10K 5% 1/4W
R608 1-247-843-11 CARBON 3.3K 5% 1/4W
R609 1-249-439-11 CARBON 68K 5% 1/4W
R610 1-247-831-11 CARBON 1K 5% 1/4W
R611 1-247-871-11 CARBON 47K 5% 1/4W
R612 1-249-429-11 CARBON 10K 5% 1/4W
R613 1-247-879-11 CARBON 100K 5% 1/4W
R614 1-249-431-11 CARBON 15K 5% 1/4W
R615 1-249-436-11 CARBON 39K 5% 1/4W
R616 1-249-428-11 CARBON 8.2K 5% 1/4W
R617 1-249-428-11 CARBON 8.2K 5% 1/4W
R618 1-247-879-11 CARBON 100K 5% 1/4W
R619 1-247-879-11 CARBON 100K 5% 1/4W
R620 1-247-847-11 CARBON 4.7K 5% 1/4W
R621 1-249-429-11 CARBON 10K 5% 1/4W
R622 1-249-429-11 CARBON 10K 5% 1/4W
R623 1-249-429-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV601 1-227-661-11 RES, VAR, CARBON 10K (BASS BOOST)
RV602 1-225-826-11 RES, VAR, CARBON 20K (LEVEL)
< SWITCH >
S601 1-786-490-11 SWITCH, SLIDE (POWER SAVE)
S602 1-786-490-11 SWITCH, SLIDE (PHASE)
*************************************************************
LED BOARD
*********
< CONNECTOR >
* BC201 1-564-519-11 PLUG, CONNECTOR 4P
< DIODE >
D202 8-719-064-11 LED SPR-325MVW (ON/STANDBY)
*************************************************************
CONTROL
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
LED
