Basic Operations
HT-DDW750 4-244-183-11(1) GB
21
GB
Changing the display
DIMMER
Press DIMMER repeatedly to adjust the
brightness of the display (3 steps).
However, when you press any button, the
display becomes the brightest setting
temporary.
DISPLAY
Each time you press DISPLAY, the display
changes cyclically as follows:
Index name of the component* t Selected
component t Sound field applied to the
program source
When the tuner is selected
Index name of the preset station* or program
station name** t Frequency t Program type
indication** t Radio text** t Current
time** t Sound field applied to the band or
the preset station
* Index name appears only when you have assigned
one to the component or preset station (page 33).
Index name does not appear when only blank
spaces have been entered, or it is the same as the
input selector.
** During RDS reception only. (Models of area code
CEL, CEK only. See page 31).
01GB05BSCCA.p65 11/29/02, 2:17 PM21
