SA-WMSP87/WMSP87E
SECTION 3
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
•Abbreviation
AUS: Australian model
CND : Canadian model
E51 : Chilean and Peruvian model
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CONTROL
1-688-810-11 CONTROL BOARD (WMSP87E)
(Not Supplied) CONTROL BOARD (WMSP87)
***************
< CAPACITOR >
C801 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CNP801 1-564-519-11 PLUG, CONNECTOR 4P (WMSP87E)
CNP801 1-691-765-11 PLUG (MICRO CONNECTOR) 3P (WMSP87)
< VARIABLE RESISTOR >
RV201 1-225-826-11 RES, VAR, CARBON 20K (LEVEL)
(WMSP87E)
RV801 1-227-511-11 RES, VAR, CARBON 20K (LEVEL)
(WMSP87)
************************************************************
1-688-813-11 INPUT BOARD (WMSP87E)
(Not Supplied) INPUT BOARD (WMSP87)
************
< CAPACITOR >
C101 1-128-813-11 CERAMIC 220PF 5% 50V
C201 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN101 1-506-944-11 PIN, CONNECTOR 2P
< JACK >
J101 1-815-025-11 JACK, PIN 1P (INPUT)
< RESISTOR >
R110 1-247-879-91 CARBON 100K 5% 1/4W
R202 1-247-831-91 CARBON 1K 5% 1/4W
************************************************************
1-688-812-11 LED BOARD (WMSP87E)
**********
< CONNECTOR >
* CN901 1-564-517-11 PLUG, CONNECTOR 2P
< DIODE >
D901 8-719-057-10 DIODE LNJ301MPUJAB (POWER)
************************************************************
A-1108-655-A MAIN BOARD, COMPLETE (US, CND)
A-1109-270-A MAIN BOARD, COMPLETE (MX, SP, E51, AUS)
A-4734-911-A MAIN BOARD, COMPLETE (WMSP87E)
*********************
< CAPACITOR >
C203 1-136-165-00 FILM 0.1uF 5% 50V
(WMSP87E)
C203 1-131-696-11 FILM 0.22uF 5% 50V
(WMSP87)
C204 1-136-165-00 FILM 0.1uF 5% 50V
(WMSP87E)
C204 1-131-696-11 FILM 0.22uF 5% 50V
(WMSP87)
C205 1-126-964-11 ELECT 10uF 20% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-131-679-31 FILM 0.01uF 5% 50V
(WMSP87E)
C207 1-136-157-00 FILM 0.022uF 5% 50V
(WMSP87)
C208 1-131-696-11 FILM 0.22uF 5% 50V
(WMSP87E)
C208 1-131-702-11 FILM 0.68uF 5% 50V
(WMSP87)
C209 1-128-813-11 CERAMIC 220PF 5% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-128-813-11 CERAMIC 220PF 5% 50V
C301 1-128-813-11 CERAMIC 220PF 5% 50V
C302 1-126-964-11 ELECT 10uF 20% 50V
C303 1-104-658-91 ELECT 100uF 20% 10V
C304 1-126-968-11 ELECT 100uF 20% 50V
C305 1-126-968-11 ELECT 100uF 20% 50V
C306 1-128-582-11 ELECT 10uF 20% 100V
(WMSP87)
C306 1-126-964-11 ELECT 10uF 20% 50V
(WMSP87E)
C307 1-126-967-11 ELECT 47uF 20% 50V
C308 1-128-582-11 ELECT 10uF 20% 100V
(WMSP87)
C308 1-126-964-11 ELECT 10uF 20% 50V
(WMSP87E)
C309 1-136-165-00 FILM 0.1uF 5% 50V
C310 1-136-165-00 FILM 0.1uF 5% 50V
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
MX : Mexican model
SP : Singapore model
LED MAIN
INPUT
