SA-WX700
SECTION 4
ELECTRICAL PARTS LIST
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
When indicating parts by reference num-
ber, please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
• Abbreviation
CND : Canadian model
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
CONNECTOR BOARD
***************
< CONNECTOR >
CN301 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
* CN303 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< SWITCH >
SW301 1-786-567-11 SWITCH, SLIDE (PHASE)
SW302 1-786-567-11 SWITCH, SLIDE (BOOST)
SW303 1-786-567-11 SWITCH, SLIDE (POWER SAVE)
*****************************************************
CONTROL BOARD
*************
< CONNECTOR >
CN302 1-564-509-11 PLUG, CONNECTOR 6P
< VARIABLE RESISTOR >
VR301 1-227-588-11 RES, VAR(LEVEL)
VR302
*****************************************************
1-688-703-11 FILTER BOARD
***********
< CAPACITOR >
C205 1-136-174-00 MYLAR 0.56uF 5% 50V
C206 1-130-325-91 FILM 0.15uF 5% 100V
C207 1-136-175-00 MYLAR 0.68uF 5% 50V
C208 1-136-175-00 MYLAR 0.68uF 5% 50V
C209 1-136-170-00 MYLAR 0.27uF 5% 50V
C210 1-136-170-00 MYLAR 0.27uF 5% 50V
C213 1-126-964-11 ELECT 10uF 20% 50V
C214 1-126-964-11 ELECT 10uF 20% 50V
C215 1-130-329-11 FILM 0.22uF 5% 100V
C216 1-130-321-11 FILM 0.1uF 5% 100V
C218 1-130-329-11 FILM 0.22uF 5% 100V
C220 1-130-329-11 FILM 0.22uF 5% 100V
C221 1-130-321-11 FILM 0.1uF 5% 100V
C222 1-130-321-11 FILM 0.1uF 5% 100V
C223 1-126-964-11 ELECT 10uF 20% 50V
C224 1-126-964-11 ELECT 10uF 20% 50V
C225 1-130-955-00 FILM 0.01uF 5% 100V
C226 1-130-955-00 FILM 0.01uF 5% 100V
C227 1-126-964-11 ELECT 10uF 20% 50V
C229 1-126-964-11 ELECT 10uF 20% 50V
C230 1-126-964-11 ELECT 10uF 20% 50V
C231 1-136-165-00 MYLAR 0.1uF 5% 50V
C232 1-136-165-00 MYLAR 0.1uF 5% 50V
C234 1-126-964-11 ELECT 10uF 20% 50V
C235 1-126-964-11 ELECT 10uF 20% 50V
C237 1-136-230-00 FILM 0.0022uF 5% 100V
C238 1-126-964-11 ELECT 10uF 20% 50V
C239 1-162-282-31 CERAMIC 100PF 10% 50V
C241 1-130-315-91 FILM 0.056uF 5% 100V
C242 1-136-173-00 MYLAR 0.47uF 5% 50V
C243 1-126-964-11 ELECT 10uF 20% 50V
C244 1-126-964-11 ELECT 10uF 20% 50V
C245 1-130-321-11 FILM 0.1uF 5% 100V
C246 1-130-321-11 FILM 0.1uF 5% 100V
< CONNECTOR >
* CN201 1-564-508-11 PLUG, CONNECTOR 5P
* CN202 1-506-611-11 PIN, CONNECTOR 8P
CN203 1-564-509-11 PLUG, CONNECTOR 6P
* CN204 1-564-511-11 PLUG, CONNECTOR 8P
< IC >
IC201 8-759-076-15 IC KIA4558P
IC202 8-759-076-15 IC KIA4558P
IC203 8-759-076-15 IC KIA4558P
IC204 8-759-076-15 IC KIA4558P
IC205 6-704-362-01 IC KIA358P
IC207 8-759-076-15 IC KIA4558P
< RESISTOR >
R201 1-249-427-11 CARBON 6.8K 5% 1/4W
R202 1-249-427-11 CARBON 6.8K 5% 1/4W
R203 1-249-429-11 CARBON 10K 5% 1/4W
R204 1-249-429-11 CARBON 10K 5% 1/4W
R205 1-249-429-11 CARBON 10K 5% 1/4W
R206 1-249-426-11 CARBON 5.6K 5% 1/4W
R207 1-249-425-11 CARBON 4.7K 5% 1/4W
R208 1-249-439-11 CARBON 68K 5% 1/4W
R209 1-249-425-11 CARBON 4.7K 5% 1/4W
R210 1-249-433-11 CARBON 22K 5% 1/4W
R211 1-249-437-11 CARBON 47K 5% 1/4W
R212 1-249-430-11 CARBON 12K 5% 1/4W
R213 1-249-432-11 CARBON 18K 5% 1/4W
R214 1-249-437-11 CARBON 47K 5% 1/4W
R215 1-249-425-11 CARBON 4.7K 5% 1/4W
R216 1-249-425-11 CARBON 4.7K 5% 1/4W
R217 1-249-427-11 CARBON 6.8K 5% 1/4W
CONNECTOR
CONTROL
FILTER
