Sony SDM-HS73 Service Manual

– 2 –
SDM-HS73 (E)
There are some different LCD panels are used in the model SDM-HS73.
Therefore the repair parts are also different.
Please confirm the serial number before repairing.
LGE Production
AU Panel LPL Panel
WHITE U/C 17-4445-10 SDM-HS73/WC UC7
6,000,001-6,080,000 6,080,001-6,200,000
GRAY U/C 17-4461-10 SDM-HS73/HC UC7
3,200,001-3,260,000
6,750,001-6,850,000
3,260,001-3,350,000
BLUE U/C 17-4458-10 SDM-HS73/LC UC7
3,500,001-3,580,000 3,580,001-3,700,000
BLACK U/C 17-4570-10 SDM-HS73/BC UC7
9,940,001-9,948,000 9,948,001-9,960,000
WHITE AEP 17-4445-20 SDM-HS73/WC EKZ
6,200,001-6,280,000 6,280,001-6,400,000
GRAY AEP 17-4461-20 SDM-HS73/HC EKZ
3,350,001-3,410,000 3,410,001-3,500,000
BLUE AEP 17-4458-20 SDM-HS73/LC EKZ
3,700,001-3,780,000 3,780,001-3,900,000
BLACK AEP 17-4570-20 SDM-HS73/BC EKZ
1,260,001-1,320,000 1,320,001-1,400,000
WHITE CH 17-4445-30 SDM-HS73/WC CN6
6,615,001-6,630,000 6,600,001-6,615,000
GRAY CH 17-4461-30 SDM-HS73/HC CN6
6,645,001-6,660,000 6,630,001-6,645,000
BLACK CH 17-4570-30 SDM-HS73/BC CN6
9,965,001-9,970,000 9,960,001-9,965,000
Color
Serial Number
DescriptionProduct CodeDest.
TPV Production
Color Destination Serial Number LCD Panel
1,000,001-1,060,000 CPT Panel
1,060,001-1,100,000 AU Panel
1,210,001-1,222,000 CPT Panel
1,222,001-1,230,000 AU Panel
1,100,001-1,160,000 CPT Panel
1,160,001-1,200,000 AU Panel
1,230,001-1,242,000 CPT Panel
1,242,001-1,250,000 AU Panel
1,200,001-1,206,000 CPT Panel
1,206,001-1,210,000 AU Panel
1,250,001-1,256,000 CPT Panel
1,256,001-1,260,000 AU Panel
1,400,001-1,460,000 CPT Panel
1,460,001-1,500,000 AU Panel
1,500,001-1,530,000 CPT Panel
1,530,001-1,550,000 AU Panel
Blue
U/C
AEP
Black
U/C
AEP
White
U/C
AEP
Grey
U/C
AEP
