- 7-
SDM-HS73 (E)
WIRING DIAGRAM
GENESS
J705
J702
J710
CN3
CN1
CN2
CN4
Connector Ass’y
P/N: 6631T11012Q
Connector Ass’y
P/N: 6620K00002D
Connector Ass’y
P/N: 6631T20022J
Connector Ass’y
P/N: 6631T20023A
