Sony STR-DE675 Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
33
STR-DE675
C1313 1-163-259-91 CERAMIC CHIP 220PF 5.00% 50V
C1501 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C1502 1-126-965-11 ELECT 22uF 20.00% 50V
C1503 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1504 1-126-964-11 ELECT 10uF 20.00% 50V
C1505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1506 1-126-935-11 ELECT 470uF 20.00% 16V
C1507 1-126-964-11 ELECT 10uF 20.00% 50V
C1508 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1509 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1510 1-104-664-11 ELECT 47uF 20.00% 16V
C1513 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1514 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1515 1-126-964-11 ELECT 10uF 20.00% 50V
C1551 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C1552 1-126-965-11 ELECT 22uF 20.00% 50V
C1601 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1602 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1603 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1604 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1605 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1606 1-104-664-11 ELECT 47uF 20.00% 16V
C1607 1-126-963-11 ELECT 4.7uF 20.00% 50V
C1608 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1609 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1610 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1611 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1612 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1613 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C1614 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C1615 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C1616 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C1617 1-126-957-11 ELECT 0.22uF 20.00% 50V
C1618 1-126-964-11 ELECT 10uF 20.00% 50V
C1619 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1620 1-126-960-11 ELECT 1uF 20.00% 50V
C1621 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1622 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1623 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1626 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1627 1-104-905-11 CAPACITOR 0.22F 5.5V
C1628 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C1629 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C1630 1-126-959-11 CAP, ELECT 0.47 20% 50V
C1901 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1902 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1903 1-126-936-11 ELECT 3300uF 20.00% 16V
C1905 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1906 1-126-935-11 ELECT 470uF 20.00% 10V
C1907 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1908 1-126-935-11 ELECT 470uF 20.00% 10V
C1909 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1910 1-126-935-11 ELECT 470uF 20.00% 10V
C1911 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1912 1-126-935-11 ELECT 470uF 20.00% 10V
C1913 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
* CNP5 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
* CNP6 1-564-731-11 PIN, CONNECTOR (SMALL TYPE)15P
* CNS1 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
CNS2 1-784-041-11 CONNECTOR, BOARD TO BOARD 9P
* CNS3 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
CNS4 1-569-327-11 SOCKET, CONNECTOR 27P
CNS7 1-569-321-11 SOCKET, CONNECTOR 15P
CNS8 1-568-439-11 SOCKET, CONNECTOR 7P
< DIODE >
D1001 8-719-016-74 DIODE 1SS352-TPH3
D1101 8-719-016-74 DIODE 1SS352-TPH3
D1501 8-719-049-09 DIODE 1SS367-T3SONY
D1502 8-719-049-09 DIODE 1SS367-T3SONY
D1601 8-719-016-74 DIODE 1SS352-TPH3
D1602 8-719-016-74 DIODE 1SS352-TPH3
D1603 8-719-016-74 DIODE 1SS352-TPH3 (US,CND)
D1901 8-719-053-18 DIODE 1SR154-400TE-25
D1902 8-719-053-18 DIODE 1SR154-400TE-25
D1903 8-719-053-18 DIODE 1SR154-400TE-25
D1904 8-719-053-18 DIODE 1SR154-400TE-25
D1911 8-719-053-18 DIODE 1SR154-400TE-25
D1912 8-719-053-18 DIODE 1SR154-400TE-25
D1913 8-719-053-18 DIODE 1SR154-400TE-25
D1914 8-719-053-18 DIODE 1SR154-400TE-25
< FERRITE BEAD >
FB1101 1-414-813-11 FERRITE 0UH
FB1102 1-414-813-11 FERRITE 0UH
FB1104 1-469-152-11 FERRITE 0UH
--55 FB1105 1-469-152-11 FERRITE 0UH
FB1201 1-414-813-11 FERRITE 0UH
FB1202 1-414-813-11 FERRITE 0UH
FB1203 1-469-152-11 FERRITE 0UH
FB1204 1-469-152-11 FERRITE 0UH
FB1501 1-414-813-11 FERRITE 0UH
FB1502 1-414-813-11 FERRITE 0UH
FB1601 1-414-813-11 FERRITE 0UH
FB1602 1-414-813-11 FERRITE 0UH
FB1603 1-414-813-11 FERRITE 0UH
< IC >
IC1101 8-759-825-15 IC LC89056W-E
IC1102 8-759-242-70 IC TC7WU04F (TE12R)
IC1103 8-759-595-15 IC TC74ACT153AF (EL)
IC1104 8-749-017-36 IC TORX-179 (DVD/LD IN)
IC1105 8-749-923-05 TORX178B (TV/SAT IN)
IC1106 8-749-923-05 TORX178B (MD/TAPE IN)
IC1107 8-749-923-04 IC TOTX178A (MD/TAPE OUT)
IC1201 8-759-698-76 IC CXD9617R
IC1202 8-759-538-16 IC IDT71V016S15PH-AUTL
IC1301 8-759-557-36 IC BU1924F-E2 (AEP, UK)
IC1501 8-759-657-47 IC AK4527
IC1502 8-759-636-74 IC NJM4565DD
IC1503 8-759-701-75 IC NJM7805FA
IC1552 8-759-636-74 IC NJM4565DD
IC1601 8-759-832-67 IC MB90478PF-G-101-BND
DIGITAL
