Sony STR-DE675 Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
36
STR-DE675
R1902 1-220-753-11 CEMENTED 6.8 5% 5W
< VIBRATOR >
X1101 1-781-465-21 VIBRATOR, CRYSTAL 12.288MHz
X1201 1-795-264-21 VIBRATOR, CERAMIC 13.5 MHz
X1301 1-579-900-21 VIBRATOR, CRYSTAL 4.33MHz (AEP,UK)
X1601 1-795-318-11 OSCILLATOR, CERAMIC 20.0MHz
************************************************************
A-4475-808-A DISPLAY BOARD, COMPLETE (US)
***********************
A-4475-875-A DISPLAY BOARD, COMPLETE (CND)
***********************
A-4475-888-A DISPLAY BOARD, COMPLETE (AEP,UK,AR)
***********************
A-4475-948-A DISPLAY BOARD, COMPLETE (AUS)
***********************
A-4475-951-A DISPLAY BOARD, COMPLETE (MY,SP,KR,CH)
***********************
A-4475-882-A DISPLAY BOARD, COMPLETE (E)
***********************
A-4476-952-A DISPLAY BOARD, COMPLETE (MX)
***********************
A-4475-943-A DISPLAY BOARD, COMPLETE (TW)
***********************
* 3-386-245-11 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C100 1-164-159-11 CERAMIC 0.1uF 50V
C101 1-164-159-11 CERAMIC 0.1uF 50V
C104 1-164-159-11 CERAMIC 0.1uF 50V
C105 1-126-795-11 ELECT 10uF 20.00% 50V
C108 1-164-159-11 CERAMIC 0.1uF 50V
C109 1-164-159-11 CERAMIC 0.1uF 50V
C110 1-128-809-11 CERAMIC 100PF 5% 50V
C111 1-128-809-11 CERAMIC 100PF 5% 50V
C112 1-128-809-11 CERAMIC 100PF 5% 50V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-126-795-11 ELECT 10uF 20.00% 50V
C144 1-164-159-11 CERAMIC 0.1uF 50V
C150 1-164-159-11 CERAMIC 0.1uF 50V
C151 1-126-795-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
CNP102 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CNS100 1-569-327-11 SOCKET, CONNECTOR 27P
< DIODE >
D100 8-719-075-59 DIODE SELS5B23C-TP15 (Digital Cinema Sound)
D101 8-719-046-39 DIODE SEL5821A-TP15 (EQ)
D102 8-719-084-07 DIODE SEL5E20CTP15
(MULTI CHANNEL DECODING)
D103 8-719-046-39 DIODE SEL5821A-TP15 (A.F.D.)
D104 8-719-046-39 DIODE SEL5821A-TP15 (2CH)
D105 8-719-046-39 DIODE SEL5821A-TP15 (MODE)
D106 8-719-046-39 DIODE SEL5821A-TP15 (SUR)
D107 8-719-046-39 DIODE SEL5821A-TP15 (LEVEL)
D108 8-719-046-39 DIODE SEL5821A-TP15 (NAME)
D109 8-719-046-39 DIODE SEL5821A-TP15 (SET UP)
< FILTER >
FL101 1-518-718-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-491-33 IC TC74VHCT08AF(EL)
IC102 8-749-011-22 IC GP1U27X (REMOTE CONTROL)
< TRANSISTOR >
Q100 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q101 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q102 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q103 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q104 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q105 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R100 1-249-413-11 CARBON 470 5% 1/4W F
R101 1-249-417-11 CARBON 1K 5% 1/4W F
R102 1-249-417-11 CARBON 1K 5% 1/4W F
R103 1-249-421-11 CARBON 2.2K 5% 1/4W F
R104 1-249-421-11 CARBON 2.2K 5% 1/4W F
R105 1-249-425-11 CARBON 4.7K 5% 1/4W F
R106 1-249-429-11 CARBON 10K 5% 1/4W
R107 1-249-413-11 CARBON 470 5% 1/4W F
R108 1-249-417-11 CARBON 1K 5% 1/4W F
R109 1-249-417-11 CARBON 1K 5% 1/4W F
R110 1-249-421-11 CARBON 2.2K 5% 1/4W F
R111 1-249-421-11 CARBON 2.2K 5% 1/4W F
R112 1-249-425-11 CARBON 4.7K 5% 1/4W F
R113 1-249-429-11 CARBON 10K 5% 1/4W
R114 1-249-433-11 CARBON 22K 5% 1/4W
R115 1-249-437-11 CARBON 47K 5% 1/4W
R116 1-249-413-11 CARBON 470 5% 1/4W F
R117 1-249-417-11 CARBON 1K 5% 1/4W F
R118 1-249-417-11 CARBON 1K 5% 1/4W F
R119 1-249-421-11 CARBON 2.2K 5% 1/4W F
R120 1-249-421-11 CARBON 2.2K 5% 1/4W F
R121 1-249-425-11 CARBON 4.7K 5% 1/4W F
R122 1-249-429-11 CARBON 10K 5% 1/4W
R123 1-249-433-11 CARBON 22K 5% 1/4W
(AEP,UK,AR)
R125 1-249-413-11 CARBON 470 5% 1/4W F
R126 1-249-417-11 CARBON 1K 5% 1/4W F
R127 1-249-417-11 CARBON 1K 5% 1/4W F
R128 1-249-421-11 CARBON 2.2K 5% 1/4W F
R129 1-249-421-11 CARBON 2.2K 5% 1/4W F
R130 1-249-425-11 CARBON 4.7K 5% 1/4W F
R131 1-249-429-11 CARBON 10K 5% 1/4W
R137 1-249-403-11 CARBON 68 5% 1/4W F
R138 1-249-409-11 CARBON 220 5% 1/4W F
R139 1-249-409-11 CARBON 220 5% 1/4W F
R140 1-249-409-11 CARBON 220 5% 1/4W F
R141 1-249-421-11 CARBON 2.2K 5% 1/4W F
R142 1-249-421-11 CARBON 2.2K 5% 1/4W F
R143 1-249-421-11 CARBON 2.2K 5% 1/4W F
R144 1-249-421-11 CARBON 2.2K 5% 1/4W F
R145 1-249-409-11 CARBON 220 5% 1/4W F
DIGITAL DISPLAY
