52
STR-K7000
Pin No. Pin Name I/O Pin Description
54 B33 I TMDS data (negative) input (Not used in this set)
55 A33 I TMDS data (positive) input (Not used in this set)
56 VCC — Power supply pin (+3.3 V)
57 B34 I TMDS data (negative) input (Not used in this set)
58 A34 I TMDS data (positive) input (Not used in this set)
59 GND — Ground
60 NC — Not used (Open)
61 VCC — Power supply pin (+3.3 V)
62 HPD2 O Hot plug detection signal output for HDMI DVD IN connector
63 SDA2 I/O I2C two-way data bus with HDMI DVD IN connector
64 SCL2 I I2C clock signal input from HDMI DVD IN connector
65, 66 GND — Ground
67 B21 I TMDS clock signal (negative) input from HDMI DVD IN connector
68 A21 I TMDS clock signal (positive) input from HDMI DVD IN connector
69 VCC — Power supply pin (+3.3 V)
70 B22 I TMDS data (negative) input from HDMI DVD IN connector
71 A22 I TMDS data (positive) input from HDMI DVD IN connector
72 GND — Ground
73 B23 I TMDS data (negative) input from HDMI DVD IN connector
74 A23 I TMDS data (positive) input from HDMI DVD IN connector
75 VCC — Power supply pin (+3.3 V)
76 B24 I TMDS data (negative) input from HDMI DVD IN connector
77 A24 I TMDS data (positive) input from HDMI DVD IN connector
78 GND — Ground
79 VCC — Power supply pin (+3.3 V)
80 HPD1 O Hot plug detection signal output for HDMI VIDEO 2 IN connector
To Next Page
