– 15 –
NOTE:
Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
-XX and -X mean standardized parts, so they
may have some difference from the original one.
RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
CAPACITORS
uF: µF
COILS
uH: µH
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
When indicating parts by reference
number, please include the board.
* 1-659-954-11 AC IN BOARD
***********
< TRANSFORMER >
! T1 1-429-447-11 TRANSFORMER, POWER
************************************************************
* 1-659-952-11 AC SW BOARD
************
1-533-293-11 FUSE HOLDER
< CONNECTOR >
* CN1 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
CN2 1-564-321-00 PIN, CONNECTOR 2P
< FUSE >
! F1 1-532-502-51 FUSE,TIME-LAG (T1.25A 250V)
< SWITCH >
! S1 1-554-920-11 SWITCH, PUSH (1 KEY) (POWER)
************************************************************
* 1-659-955-11 CN DC BOARD
***********
< CAPACITOR >
C901 1-106-379-12 MYLAR 0.033uF 5% 200V
C902 1-106-379-12 MYLAR 0.033uF 5% 200V
< CONNECTOR >
* CN901 1-564-241-11 PIN, CONNECTOR (B4P-VH) 4P
< DIODE >
D901 8-719-028-23 DIODE D3SBA20-4101
D906 8-719-200-82 DIODE 11ES2
< RESISTOR >
R911 1-249-431-11 CARBON 15K 5% 1/4W
************************************************************
* A-4389-375-A CONTROL BOARD, COMPLETE
************************
< CAPACITOR >
C201 1-136-153-00 FILM 0.01uF 5% 50V
C202 1-136-165-00 FILM 0.1uF 5% 50V
C203 1-130-477-00 MYLAR 0.0033uF 5% 50V
C204 1-136-159-00 FILM 0.033uF 5% 50V
C205 1-130-473-00 MYLAR 0.0015uF 5% 50V
C251 1-136-153-00 FILM 0.01uF 5% 50V
C252 1-136-165-00 FILM 0.1uF 5% 50V
C253 1-130-477-00 MYLAR 0.0033uF 5% 50V
C254 1-136-159-00 FILM 0.033uF 5% 50V
C255 1-130-473-00 MYLAR 0.0015uF 5% 50V
< CONNECTOR >
CN801 1-568-838-11 SOCKET, CONNECTOR 21P
CN802 1-562-087-00 SOCKET, CONNECTOR 4P
< DIODE >
D802 8-719-313-72 DIODE SEL3810A-CD (TAPE1/DAT)
D803 8-719-313-72 DIODE SEL3810A-CD (TAPE2/MD)
D804 8-719-313-72 DIODE SEL3810A-CD (CD)
D805 8-719-313-72 DIODE SEL3810A-CD (TUNER)
D806 8-719-313-72 DIODE SEL3810A-CD (PHONO)
< RESISTOR >
R201 1-249-433-11 CARBON 22K 5% 1/4W
R202 1-249-421-11 CARBON 2.2K 5% 1/4W
CONTROLCN DC
AC SW
SECTION 4
ELECTRICAL PARTS LIST
