Switcher Resources
Colour Correction
Output CCR for any AUX output is provided as a standard
feature with all XVS series processors. With the exception of
the simple input board, XKS-S8110, all input boards can also
provide CCR for inputs. Colour correction adjustments include:
Black, White, Gamma and Knee and independent Red, Green
and Blue channels on both darks and whites. The values of
input colour correction can be saved in setup files, whilst
output colour correction adjustments are saved in snapshot
files. A CCR Aux Bus Link feature provides copy and link
functions for duplicating and/or locking CCR values between
multiple AUX busses for fast setup and modification.
To harmonise incoming signals and correct AUX outputs for on-set monitors, venue displays and other destinations, Proc
Amp, Primary and full RGB colour correction are available for both inputs and outputs on the XVS processor.
Colour correction menu control
Multi Viewer Outputs
The XVS processor provides two
channels (XVS-6000, 7000 &
8000) or four channels (XVS-
9000) of multi viewer output
available via one of the primary
output boards. Each multiviewer
can be independently configured.
Any internal or external source
can be routed to the multi viewers
which support 4, 10, 13 or 16 pane
view modes. Multiviewers are
available in HD or UHD and can
also display source names and
tally for each source.
Multi viewers in 4, 10, 13 and 16 panel display modes
