NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 70 —
SECTION 9
ELECTRICAL PARTS LIST
• Abbreviation
CND : Canadian
IT : Italian
* 1-666-860-11 BATTERY (L) BOARD (US,CND)
*****************
* 1-666-860-21 BATTERY (L) BOARD (AEP,IT,UK,E)
*****************
3-017-439-01 SPRING (-) (L), BATTERY
************************************************************
* 1-666-861-11 BATTERY (S) BOARD (US,CND)
*****************
* 1-666-861-21 BATTERY (S) BOARD (AEP,IT,UK,E)
*****************
3-939-057-01 SPRING (-), BACK UP
< CONNECTOR >
CN903 1-564-505-11 PLUG, CONNECTOR 2P
CN904 1-564-506-11 PLUG, CONNECTOR 3P
************************************************************
* 1-639-678-12 CD MOTOR BOARD
****************
1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
1-572-085-11 SWITCH, LEAF
************************************************************
* A-3321-148-A CONTROL BOARD, COMPLETE (US,CND)
*************************
* A-3321-186-A CONTROL BOARD, COMPLETE (AEP,IT,UK,E)
*************************
3-017-444-01 HOLDER, LCD
3-019-236-01 ILLUMINATOR (LCD)
7-685-535-14 SCREW +BTP 2.6X10 TYPE2 N-S
< CAPACITOR >
C800 1-164-159-21 CERAMIC 0.1uF 50V
C801 1-164-159-21 CERAMIC 0.1uF 50V
C803 1-162-306-11 CERAMIC 0.01uF 30% 16V
C806 1-126-967-11 ELECT 47uF 20% 10V
C807 1-126-964-11 ELECT 10uF 20% 50V
C808 1-102-514-11 CERAMIC 22PF 5% 50V
C809 1-102-516-11 CERAMIC 27PF 5% 50V
C810 1-162-282-31 CERAMIC 100PF 10% 50V
C811 1-162-282-31 CERAMIC 100PF 10% 50V
C812 1-102-960-00 CERAMIC 24PF 5% 50V
C813 1-102-960-00 CERAMIC 24PF 5% 50V
C815 1-136-165-00 FILM 0.1uF 5% 50V
C817 1-162-306-11 CERAMIC 0.01uF 30% 16V
C818 1-162-306-11 CERAMIC 0.01uF 30% 16V
C819 1-102-960-00 CERAMIC 24PF 5% 50V
C820 1-102-960-00 CERAMIC 24PF 5% 50V
C822 1-162-294-31 CERAMIC 0.001uF 10% 50V
C823 1-162-294-31 CERAMIC 0.001uF 10% 50V
C824 1-162-294-31 CERAMIC 0.001uF 10% 50V
C825 1-136-165-00 FILM 0.1uF 5% 50V
C826 1-162-294-31 CERAMIC 0.001uF 10% 50V
C827 1-162-294-31 CERAMIC 0.001uF 10% 50V
C828 1-162-294-31 CERAMIC 0.001uF 10% 50V
C829 1-162-294-31 CERAMIC 0.001uF 10% 50V
C830 1-162-294-31 CERAMIC 0.001uF 10% 50V
C831 1-162-294-31 CERAMIC 0.001uF 10% 50V
C832 1-162-294-31 CERAMIC 0.001uF 10% 50V
C833 1-162-294-31 CERAMIC 0.001uF 10% 50V
C834 1-162-294-31 CERAMIC 0.001uF 10% 50V
C835 1-162-294-31 CERAMIC 0.001uF 10% 50V
C836 1-162-294-31 CERAMIC 0.001uF 10% 50V
C837 1-162-294-31 CERAMIC 0.001uF 10% 50V
C838 1-162-294-31 CERAMIC 0.001uF 10% 50V
C839 1-162-294-31 CERAMIC 0.001uF 10% 50V
C841 1-162-294-31 CERAMIC 0.001uF 10% 50V
C842 1-162-294-31 CERAMIC 0.001uF 10% 50V
C843 1-162-294-31 CERAMIC 0.001uF 10% 50V
C844 1-162-294-31 CERAMIC 0.001uF 10% 50V
C845 1-162-294-31 CERAMIC 0.001uF 10% 50V
(US,CND)
C846 1-162-282-31 CERAMIC 100PF 10% 50V
C847 1-162-282-31 CERAMIC 100PF 10% 50V
C848 1-162-294-31 CERAMIC 0.001uF 10% 50V
C849 1-162-282-31 CERAMIC 100PF 10% 50V
C850 1-162-306-11 CERAMIC 0.01uF 30% 16V
C851 1-162-282-31 CERAMIC 100PF 10% 50V
(US,CND)
C852 1-162-306-11 CERAMIC 0.01uF 30% 16V
(AEP,IT,UK,E)
C853 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
CN801 1-691-071-31 HOUSING, CONNECTOR 12P
* CN802 1-695-381-31 PIN, CONNECTOR (PC BOARD) 20P
CN803 1-695-388-21 PIN, CONNECTOR (PC BOARD) 27P
* CN804 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-991-33 DIODE 1SS133T-77
D803 8-719-991-33 DIODE 1SS133T-77
D804 8-719-991-33 DIODE 1SS133T-77
CD MOTOR
BATTERY (S)BATTERY (L)
CONTROL
To Next Page
