South-Tek Systems N2Blast FPS-650 User Manual

FPS-650 and FPS-1250 South-Tek Systems
Version: 7
Revision Date: 9/6/19 Page 7 of 29
3 SYSTEM DESCRIPTION
KEY FEATURES
The FPS-650 and FPS-1250 key features include the following:
- Air compressor
- Air Filters
- Programmable Logic Controller (PLC)
- Pressure Swing Adsorption Beds
- Safety Relief Valves
- N2 Storage Tank
- Automatic Pressure Cut-in/Cut-out
- STS Patented Blast-Off (optional)
Air Compressor:
The air compressor is designed internally to the cabinet and features
engineered dampening system to reduce vibration and noise throughout the
cabinet. It is an oil-less compressor with a pre-filter attached to the air input.
The recommended replacement on the pre-filter is 1000 run hours or 1 year
(whichever comes first). Dirtier environments may be required to be changed
out more frequently. Consult your supplier for a different filter maintenance
schedule if you are installing the generator in dirty environment.
Air Filters:
The generator has two filters after the air compressor: the particulate and
coalescing. The Particulate has a 5-micron filter that will catch any of the
larger particles. The Coalescing has a 0.1-micron filter that will catch the
remaining smaller particles. Both filters feature and auto-drain that will drain
the water captured after the air compressor. The drain is plumbed to the
outside of the cabinet where the end-user can then connect ¼” tubing and
drain to a safe location.
Programmable Logic Controller (PLC):
There’s an integrated PLC within the cabinet. It features smart and efficient
coding to maximize the performance of the generator. It controls the timing
and sequencing of the valves to effectively move compressed gas
throughout the system. It also has a smart feature to automatically go into
different “modes” based on the current run stages. It comes with a visual
screen that will display run hours and alarms.
