1
5
13
14
4
12
7
8
10
9
2
11
6
Spare Parts List HL 1810 S
Part No.
Pos.
02818
—
02420
02621
02523
02629
02723
—
02829
02318
02218
02118
02426
1 +2
3
4
5
6
7
8 + 10
9
11
12
13
14
15
HL 1810 S, Type 3481
Housing Set incl. Labels
End Cap
Switch with Markings (external)
Softgrip
Outlet Protection Tube
Rubber Soft Stand
Power Cord with Strain Relief
Power Cord Connector
Set of 5 Housing Screws
PCB/IC Block with Switch (internal)
Motor/Fan Assembly
Heating Element 1400W/120V
Switch (internal)
- 11 -
English
blue
blue
red
yellow
red
Wiring Diagram HL 1810 S
3
15
white
black
HL1610S_USA 20.05.2005 15:40 Uhr Seite 12
