STEINEL Masterline Series User Manual

white
black
2:1
green
green
red
red
blue
blue
yellow
yellow (fuse)
- 15 -
English
Wiring Diagram HG 2510 ESD
7
Spare Parts List HG 2510 ESD
Part No.
Pos.
02825
02425
02621
02629
02725
02525
—
02829
02325
02225
02125
02426
1 + 2
3
4
5
6 + 8
7
9
10
11
12
13
14
HG 2510 ESD, Type 3488
Housing Set incl. Labels (ESD)
Switch with Markings (external)
Softgrip
Rubber Soft Stand
Power Cord with Strain Relief (ESD)
Outlet Protection Tube (ESD)
Power Cord Connector
Set of 5 Housing Screws
PCB/IC Block with Switch and Controls (ESD)
Motor/Fan Assembly
Heating Element 1600W/120V (ESD)
Switch (internal)
14
3
11
5
6
8
9
10
2
13
124 1
HL1610S_USA 20.05.2005 15:40 Uhr Seite 16

STEINEL Masterline Series Specifications

General

Brand	STEINEL
Model	Masterline Series
Category	Power Tool
Language	English
