Workshop Manual, GG
P Park
6 Control wires
7
6.3.2 Adjustment (2WD)
In theory this machine can
go just as fast both
forwards and backwards. It is therefore important
that the basic position of
the hydrogear pedal is
correctly adjusted.
Procedure
1.
Adjust the distance
by moving the elbow
links on the control wi
re. See “Elbow links”
at page
3.
2.
Release the upper nut
on the stop screw
and screw down the
screw a few turns.
82
84
